Table Top Sterilizers - Autoclave

Capacity: 24, 45, 60, 80 LITERS CLASS B -An automatic high pressure rapid sterilizer which works with steam as medium. -Can be widely used in department of stomatology and ophthalmology, operating room, CSSD. -Suitable for all (un)wrapped solid instruments, A-class cavity instrument (Dental hand piece), implantable instruments, dressing fabric and rubber tubes, etc. -Stainless steel 304 chamber structure: cylinder, horizontal, single door. -Door opening method: automatic, press button. -High efficient WJS (water ejector) vacuum system, which supply high speed vacuum and low working noisy, vacuum lower limit can reach over -90kPa in short time, perfect drying performance through sterilization. Device / Programs: - 8 preset cycles - Cycle time: 45-60 min, according to different loadings - Pressure display: Analogue pressure gauge for chamber on right side - Temperature display: Digital Temperature Display on the front panel (LCD screen) - Built-in steam generator: Double Instant steam generator - Integrated programmable PLC control system with 3.2 inch LCD screen display and capacitive induction buttons enables intuitive operation. It shows the pages which are: main menu, library cycles, cycle parameters, process control, display of temperature, pressure, time, running process, error and alarm information, various of messages (working status, temperature, pressure, vacuum, etc.) Installation - Designed Pressure: -0.1~ 0.3 MPa - Vacuum low limit: -0.09 MPa - Vacuum pulses counts: 0~99 items - Designed Temperature: 144�° C - Working Temperature range: 105-138�° C - Power Supply: control Power: AC 220V �± 10% single phase 50/60 Hz - Input power: 2.6kVA (24L) or 6.8kVA (45L) or 7.4kVA (60L) - Water pure supply, inner circulation, with open type water tank with removable cover makes it easy to be cleaned Data Saving: - Sterilization cycle data (batch number date/time, temperature/pressure progress and sterilization phase) can be printed using an integrated micro printer (optional) via RS232 serial port - Data can also be stored via U disk (optional), stores up to 10 000 sterilization cycles - WI-FI module allows real time transmission of cycle data and cycle progress information to a PAD for online monitoring (documented data both graphically and numerically and can be used for control of autoclaves)
