Products from Zhongyun Intelligent Machinery (yantai) Co,. Ltd. — 194 Products

Product Name Rail clip e2055 for railway fastening system Raw Material 60Si2MnA Diameter 20mm Weight 0.765Kg Hardness HRC44-48 Fatigue Test 5 million cycles without breaking or cracking Toe Load more than 2750 bls (Deflection 11.1mm) Surface Nataral color or as customer's requirement Place of Origin Jiangsu, China (Mainland) Certification ISO9001:2008 Standard UIC,DIN,JIS,AREMA,ISCR,GB,etc Application Railway Fastening System

1, normal sleepers: Width 220mm; thickness 160mm; length 2500mm; 2, turnout sleepers (Normal): Width 220mm; thickness 160mm; length 2600 ~ 4850mm, with 150mm carry a total of 16 lengths; 3,turnout sleepers (Standard): Width 240mm; thickness 160mm; length 2600 ~ 4800mm, with 200mm carry a total of 12 lengths; 4,bridge sleepers: Width 220mm; thickness 240,260,280,300 mm; length 3000mm;

Main material: radiata pine pinus elliottii/fir/larch/mongolica, etc Low size: length: 1 m, 2 m, 4 m, 6 m, 8 m, 10 m and 12 m width: 25-400 - mm thickness: 25-400 - mm (can be customized according to customer's different requirement) Low processing way: with burrs/on every line

Introduction of 10 Kg Pesticide AgricultureSprayingDrone 10 kg spray drone 10 kg spray drone technical indicators Dimensions (length * width * height) 2110 * 2110 * 800mm Aircraft weight 11KG Maximum takeoff weight 30KG Pesticide container capacity 10L Boom length 220cm Body Material Carbon Fiber & Aluminum Alloy Charger High-power lithium balance charging device Spraying system, medicine box, diffusion spray system, booster pump Operating temperature -10°C-40°C Lithium battery life 300 times charge and discharge Maximum payload (5-20) KG (±5%) Lithium polymer power battery 22.2V/16000mA / battery life 10min Working speed 3-8m/s (wind speed 2-3) Relative flight height 1-3 meters from crops (depending on different crops) Spray width (6 0.3L/min nozzles, 2.2 meters long spray tube) 2-4 meters (downwind or upwind, wind speed 2-3) Spray flow rate 1-1.2L/min (6 nozzles) High-concentration pesticide consumption 0.5-1.0L/mu (depending on different crops) Single machine spraying operation efficiency of 300 mu / day (depending on the actual operation of the flying hand)

Technical parameterDescriptionNOTE Dimension1400-1600mmCustomize according to requirement Fold dimensionappr. 800*800*800mm Empty Weight8kg/10kg/12kg/15kgSet according to user Maximum takeoff weight12kg/16kg/20kg/25kg Maximum control distance1.5~2km Flight speed0~10m/s Spraying systemDispersion atomizer Operation time8~15min Working height1~10m Operation speed1.6~2.8Acres/10min Spraying flow0.25~0.75/min Anti-wind

Product Name Agriculture UAV Wheelbase 1350mm Working Speed 5-10m/s Max Take off Weight 22kg Max Payload 12Kg Working Altitude 0.5-5m Payload 12L Wind Risistance 5Level Duration of Flight 10-15min Working Temperature -15-50 Spray Width 4-6m(adjustable) Nozzle Type Pressure Nozzle Number of Nozzles 2 Battery 2 Pcs 12000m Ah Li-Po batteries Color Yellow Logo DIGITAL EAGLE

Can't find exactly what you need?

Post your requirement for “” and get competing quotes from 10+ verified suppliers within 24 hours — free.

Parameters unit key parameter Model 1.2M3 double Side type(N) 1.6M3 hydraulic pressure 2.5M3 Hydraulic pressure 4M3 Hydraulic pressure 6M3 Hydraulic pressure 8M3 Hydraulic pressure volume M3 1.2 1.6 2.5 4 6 8 load T 3 4 6.25 10 15 20 track gauge mm 600 762 762/900 762/900 762/900 762/900 wheel base mm 620 800 120 2000 2000 2600 wheel diameter mm 300 350 400 350 350 350 Binder shape Bolt link Bolt link Bolt link Bolt link Bolt link Bolt link Traction high mm 335 320 320 430 430 430 Uninstall Angle (.) 45 45 42 42 42 overall dimension long mm 2150 2500 3650 3650 4850 6350 wide mm 1450 1200 1250 1500 1500 1500 high mm 1270 1300 1300 1586 1586 1634 self weight 1000 1663 2505 3850 4900 6300 Traction speed km/h 12 12 12 8 8 8 turn radius m 8 10 12 15 15 18

Model loading (kg) L(mm) W(mm) H(mm) Rail gauge(mm) Wheel Dia.(mm) Pulling Height(mm) Weight (kg) MPC2-6 2000 2000 880 410 600 300 320 490 MPC3-6 3000 2400 1050 415 600 300 320 530 MPC5-6 5000 3450 1200 480 600 350 320 900 MPC5-9 5000 3450 1320 480 900 350 320 910 MPC10-6 10000 3460 1300 304 600 250 230 910 MPC10-9 10000 3460 1300 304 900 250 230 1030 MPC13-6 13000 3350 1400 342 600 300 270 1015 MPC15-6 15000 3460 1300 357 600 300 320 1160 MPC15-9 15000 3460 1300 357 900 300 320 1240 MPC18-6 18000 3350 1400 346 600 300 270 1132 MPC20-6 20000 3460 1300 364 600 300 320 1240 MPC20-9 20000 3460 1300 364 900 300 320 1320 MPC25-6 25000 3460 1300 390 600 350 320 1750 MPC25-9 25000 3460 1300 390 900 350 320 1800 MPC26-6 26000 2400 1462 390 600 240 280 1133 MPC30-6 30000 3460 1300 400 600 350 320 170 MPC30-9 30000 3460 1300 400 900 350 320 1900

Model load(t) Track Overall dimension Wheelbase Dia. of wheel Length Width Height mm YPC1-6-6 1 600 1500 850 400 500 300 YPC3-6-6 3 600 1900 1050 425 600 300 YPC3-7 3 762 1900 1050 425 600 300 YPC5-6 5 600 3000 1200 510 1000 400 YPC5-7 5 762 3000 1200 1650 1000 1000 YPC5-9 5 900 3000 1200 510 1000 320

Model MGC1.7-6 MGC1.7-9 MGC1.1-6 MGC3.3-9 Volume(m³) 1.7 1.7 1.1 3.3 Theoretical Capacity(T) 1.5 1.5 1 3 Max. Load(T) 2.7 2.7 1.8 5.3 Gauge(mm) 600 900 600 900 Wheel Base(mm) 750 600 550 1100 Wheel Diameter (mm) 300 350 300 350 Traction(KN) 60 60 60 60 Traction Height(mm) 320 320 320 320 Overall Size(L*W*H) 2400x1050x1200 2100x1150x1300 2000x880x1150 3450x1320x1300 Weight(?¤kg) 720 970 610 1320

Custom flexitank, drum and IBC packaging for edible oils. ISO certified. 10,000 MT monthly capacity.

Model Mine Car Weight kg Track mm Wheel Diameter Max Axle Distance of wheels Min distance of covers Axle diameter ZBL600/300 â?¤2400 600 300 808 510 60 ZBL762/300 762 970 672 ZBL900/300 900 1108 810 ZBL600/350 â?¤6700 600 350 850 490 80 ZBL762/350 762 1012 652 ZBL900/350 900 1150 790 ZBL600/400 â?¤9000 600 400 870 476 95

Item Unit Model of winch 2JP-7.5 3JP-7.5 2JP-15 3JP-15 2JP-30 3JP-30 2JP-55 3JP-55 2JP-75 2JP-90 2JP-110 Volume of scraper pan 0.1 0.25 0.4 0.6 1.0 1.5 1.6 Average puling Force of working drum KN 8 14 28 50 54 62 78 Average Speed of wire rope m/s 1.0 1.1 1.2 1.2 1.3 1.3 1.3 Diameter of wire rope mm 9.3 12.5 15.5 18.5 20 23 24.5 Rope capacity of drum m 45 80 90 100 180 125 110 Electric power KW 7.5 15 30 55 75 90 110 Motor speed m/s 1440 1210 1460 1525 1470 1685 1485 2070 1480 1480 1480 Overall dimension length mm 1210 1525 1685 2070 2350 2400 2600 width mm 565 660 380 1010 1515 1515 1515 height mm 490 620 735 890 1300 1300 1300

Electric scraper winch Item Unit 2JP-7.5 2JP-15 2JP-22 2JP-30 2JP-55 Pulling tension KN 8 14 20 28 50 wire rope average speed m/s 1 1.1 1.2 1.2 1.2 Wire rope diameter mm 9.3 12.5 14 15.5 18.5 Drum Diameter(mm) 205 225 280 280 350 Width(mm) 80 125 510 160 180 Main drum rope capacity m 45 80 80 90 100 Second drum rope capacity m 45 100 100 110 130 Electric power Kw 7.5 15 22 30 55 rotate speed m/s 1440 1460 1470 1470 1470 Dimension Length mm 1210 1525 1600 1650 2070 Width mm 565 660 730 820 1010 Height mm 490 620 640 700 890 Weight (main engine) KG 390 660 900 1155 2125

Name Parameter Unit Working pressure 0.69-1.0 M Pa Traction 8 K N Max rope speed 32 m/min Air motor Rated power 7.5 kW Rotating speed 1200 rpm Drum Diameter 205 mm Length 150 mm Wheel flange diameter 350 mm Wire-rope diameter 9.3 mm Rope capacity 45 m External dimension L W H 920 675 475 mm Working condition Temperature -10 +60 ° C Humidity 100% Wind speed & wave height 6 / 2 level/M Weight 360 kg

Model JK1 JK3 JK5 JK8 JK10 Line pull capacity (kg) 1000 3000 5000 8000 10000 Wire rope average speed (m/min) 30 30 28 20 19 Wire rope Dia. (mm): 9.3 15.5 21.5 26 30 Reduction box Type JZQ350 JZQ500 JZQ650 JZQ650 JZQ750 Transmission ratio 31.5 23.34 40.17 23.34 23.34 Drum (mm) Diameter 190 325 406 500 550 Length 360 520 840 900 1000 Capacity(m) 110 200 300 300 450 motor Type Y132M-4 YZR225M-8 YZR250M1-8 YZR250M1-6 YZR250M2-6 Power(kW) 7.5 22 30 37 45 Rotating speed(r/min) 1440 715 864 960 960 Hydraulic Brake YWZ-200/25 YWZ-200/25 YWZ-300/45 YWZ-300/45 YWZ-400 Dimension (cm) 945x97x60 147x140x95 186x166x95 240x180x110 250x190x120 Weight(kg) 460 1200 2700 4000 5000

Model Rated pull Average speed Rope length Motor power Out size Dead weight KN m/min m KW mm KG JM1 10 15 80 2.2 740*690*490 270 JM1.6 16 16 115 5.5 940*900*570 500 JM2 20 16 100 7.5 940*900*570 550 JM3.2 32 9.5 150 7.5 1430*1160*910 1100 JM5 50 9.5 190 11 1620*1260*948 1800 JM8 80 8 250 15 2180*1460*850 2900 JM10 100 8 200 22 2280*1500*950 3800 JM12.5 125 10 300 30 2880*2200*1550 5000 JM16 160 10 500 37 3750*2400*1850 8800 JM20 200 10 600 45 3950*2560*1950 9900 JM25 250 9 700 55 4350*2800*2030 13500 JM32 320 9 700 75 4500*2850*2100 20000 JM50 500 8 800 90 4930*3050*2250 38000 JM65 650 10 2400 160 5900*4680*3200 46000 JM65 650 10 2400 160 5900*4680*3200 46000

Reference number/type JSDB-10 JSDB-13 JSDB-19 traction KN low speed outer 100 130 190 average 120 165 250 internal 140 200 320 Fast 12 15 25 rope speed m/s Slow 0.115-0.157 0.103-0.152 0.118-0.204 Fast 0.756-1.03 0.833-1.23 0.86-1.5 reduction ratio Slow 175.62 209.66 247.44 Fast 26.89 25.82 34.13 Wire rope diameter mm 20 24 30 rope capacity m 120 180 400 motor type YBK2-200L1-6 YBK2-200L2-6 YBK2-280S-6 power KW 18.5 22 45 speed r.pm 970 970 980 Drum size mm diameter 380 400 540 width 408 531 560 overall dimension mm length 2630 3158 3845 width 770 1215(970) 1315 high 855 1030 1255 Total Weight kg 2000 2960 6500

Model Drum Steel wire rope tension Rope capacity Steel wire rope Electric motor diameter width The first layer The second layer The third layer Max diameter speed Power MM KN M MM m/s KW JTP-1.6*1.2 1600 1200 45 226 458 687 24.5 1.56-4 95-155 JTP-1.6*1.5 1600 1500 45 281 570 854 24.5 1.56-4 95-155 JTP-1.2*1.0 1200 1000 30 170 344 516 20 1.88-2.4 55-75 JTP-1.2*1.2 1200 1200 30 203 412 620 20 1.57-2.4 55-75

1.Buffer head center distance rail surface height: Standard rail vehicles:850mm Subway, light rail and other vehicles:500mm,660mm,678mm,720mm Subway, light rail and other vehicles. 2.Allow the vehicle impact speed: Footless style, according to the user needs to provide 3km / h, 5km / h, 10km / h in three models. There are basic formula: the user needs to provide 60t, 75t, 90t three models. 3.Buffer cylinder Resistance: Footless style, according to the user needs to provide 30t, 45t, 60t three models. There are basic formula: the user needs to provide 60t, 75t, 90t three models. 4.Buffer head size and shape: Standard vehicle is planar, subway, light rail and other vehicles provided by the user to match the size and shape of the coupler. 5.Vehicle kinetic energy absorbed by the buffer tank can be designed according to user requirements.

Level resistance >=15T Max. impact velocity 20km/h Distance between buffer rubber plate center and rail level 850±20mm

The allowing impact speed of the vehicle 15km/h The allowing impact quality of the vehicle 3000kn The center of the buffer head to the rail surface height For the standard rail vehicles 850mm For the subway,light rail and other vehicles 500mm,660mm,720mm For the China railway 1050mm Dimension 1400mm*1600mm*(H+300) Safe location Front bumper, rear bumper, 5m

Model Track mm Payload(kg) Operate Track QTY ZCQ-6/9/1435-18 600/9/1435 18 Handle single/double ZCQ-6-22 600/9/1435 22 Handle single/double ZCQ-6-24 600/9/1435 24 Handle single/double ZCQ-6-30 600/9/1435 30 Handle single/double ZCQ-6-38 600/9/1435 38 Handle single/double ZCQ-6-43 600/9/1435 43 Handle single/double ZCQ-6-50 600/9/1435 50 Handle single/double ZCQ-6-60 600/9/1435 60 Handle single/double ZCQ-6-75 600/9/1435 75 Handle single/double

Model Track mm Payload kg Operate Track QTY ZCQ-6/9/1435-18 600/9/1435 18 pneumatic double ZCQ-6-22 600/9/1435 22 pneumatic double ZCQ-6-24 600/9/1435 24 pneumatic double ZCQ-6-30 600/9/1435 30 pneumatic double ZCQ-6-38 600/9/1435 38 pneumatic double ZCQ-6-43 600/9/1435 43 pneumatic double ZCQ-6-50 600/9/1435 50 pneumatic double ZCQ-6-60 600/9/1435 60 pneumatic double ZCQ-6-75 600/9/1435 75 pneumatic double Model Track mm Payload kg Operate Track QTY ZCQ-6/9/1435-18 600/9/1435 18 Handle single/double ZCQ-6-22 600/9/1435 22 Handle single/double ZCQ-6-24 600/9/1435 24 Handle single/double ZCQ-6-30 600/9/1435 30 Handle single/double ZCQ-6-38 600/9/1435 38 Handle single/double ZCQ-6-43 600/9/1435 43 Handle single/double ZCQ-6-50 600/9/1435 50 Handle single/double ZCQ-6-60 600/9/1435 60 Handle single/double ZCQ-6-75 600/9/1435 75 Handle single/double

Name of Commodity Specificaton Materials Standard of Products Theory Weight Length of Dimension (m) Packed in bundle with iron wire (pcs/bundle) Light Rail 4kg/m Q235 Q/YYG001-2008 4kg/m 6,8,9,10 75 8kg/m Q235 Q/YYG001-2008 8.42kg/m 55 12kg/m Q235 GB11264-89 12.2kg/m 36 15kg/m Q235/55Q/50Q GB11264-89 15.2kg/m 28 18kg/m Q235/55Q/50Q YB222-63 18.02kg/m 21 22kg/m Q235/55Q/50Q GB11264-89 22.3kg/m 21 24kg/m Q235/55Q/50Q Q/YYG001-2008 24.46kg/m 21 30kg/m Q235/55Q/50Q GB11264-89 30.1kg/m 15

Name of Commodity Specificaton Materials Standard of Products Theory Weight Length of Dimension(m) Packed in bundle with iron wire (pcs/bundle) Heavy Rail 38kg/m U71Mn/U71/45Mn GB2585-2007 Q/YYG002-2008 38.733 12,12.5 10 43kg/m U71Mn/U71/45Mn GB2585-2007 Q/YYG002-2008 44.653 10 50kg/m U71Mn/U71/45Mn GB2585-2007 Q/YYG002-2008 51.514 10 Photos of of 43kg Railway Heavy Steel Rail

Model Head width Rail height Web Thickness Bottom Width Weight Material Rail length 38kg/m 68mm 134mm 13mm 114mm 38.733 kg/m U71Mn/U71 /45Mn 12,12.5m 43kg/m 70mm 140mm 14.5mm 114mm 44.653 kg/m U71Mn/U71 /45Mn 12,12.5m 50kg/m 70mm 152mm 15.5mm 132mm 51.514 kg/m U71Mn/U71 /45Mn 12,12.5m

Hot Rolled H-beam GB/T11263-1998 SIZE SECTION DIMENSIONS (MM) KG/M H B t1 t2 r 100X100 100 100 6 8 10 17.2 125X125 125 125 6.5 9 10 23.8 150X100 148 100 6 9 8 21.4 150X150 150 150 7 10 11 31.9 175X175 175 175 7.5 11 13 40.2 200X150 194 150 6 9 13 31.2 200X100 198 99 4.5 7 8 18.5 200X100 200 100 5.5 8 11 21.7 200X200 200 200 8 12 13 50.5 250X175 244 175 7 11 16 44.1 250X125 248 124 5 8 8 25.8 250X125 250 125 6 9 12 29.7 250X250 250 250 9 14 16 72.4 250X250 250 255 14 14 16 82.2 300X200 294 200 8 12 18 57.3

Light rail: 8kg, 9kg, 12kg, 15kg, 18kg, 22kg, 24kg and 30kg Heavy rail: 38kg, 43kg, 50kg and 60kg Crane rail: QU70, QU80, QU100 and QU120 Besides, there are so many various oversea railway fish plate: BS80A, BS80A, BS75R, UIC60 and UIC54 and UIC series, e.g. Features of fish plate Convenient to install and handle Not easy to get rusty To meet the different requirements, the joggled fish plate are usually used in recent days. It has a simple structure and can largely reduce the impact of wheels to the connecting sections of the rail tracks and increase the continuity and steadiness of the train when passing through the connecting sections. Parameter of Customized Railway Fish Plate Joint Bar For Railroad Parts Grade Q235,Q235B,50Q,55Q Rail Height 107.00mm Bottom Width 92.00mm Web Thickness 10.90mm Head Width 51.00mm Length 6m,8m,9m,10m,12m,etc Place of Origin Shandong, China (Mainland) Brand Name china coal Model Number GB11264-89 Type Light Rail Application Railway Rail Weight 24.46kg Secondary Or Not Non-secondary color as your requirement

Name of Commodity Specificaton Materials Standard of Products Theory Weight (kgs/set) Length of Dimension (cm) Packed in bundle with iron wire (set) Fish Plate 8kg Q235B GB11265-89 0.8 +0.8 =1.6 50 1+1=2 12kg GB11265-89 1.1+1.1=2.2 45.5 50 2.6-3.0 15-18kg GB11265-89 3.6-4.0 53.54 25 4.6-5.0 5.6-6.0 22-24kg GB11265-89 6.6-7.0 61.73 20 7.6-8.0 8.4-9.0 30kg GB11265-89 14.4-15.0 71.48 10 16.4-17.0 43kg GB185-63 57.0-58.0 79 1

Type Length/parameter Weight(kg) Material Material 115RE 4hole-24* 17.04 Chemical composition(%) C:0.42-0.50, Mn:0.50-0.80 Si:0.17-0.37 Cr:

Trough Width (mm) Chain speed (m/s) Transportation Capacity (t/h) Length (m) Feeding size (mm) Motor Power (kw) Weight (t) 600 0.48/0.76 50-100 17.7 0-50 5.5 9.6 800 0.48/0.76 100-200 17.7 0-50 7.5 12.9 1000 0.48/0.76 150-300 18 0-50 11 15.6 1200 0.48/0.76 400-800 18.8 0-100 18.5 20.4 1400 0.48/0.76 500-1000 19 0-200 22 24.6 -

model SGB-620/40T SGB-420/30 SGD-280/11 SGD-320/17B Transportation volume(t/h) 150 80 30 40 Design length(m) 100 100 80 80 Electromotor type JDSB-40 JDSB-30 JDSB-11 JDSB-17 power(KW) 40 30 11 17 rotate speed(r/min) 1470 1470 1450 1470 voltage(V) 380/660 380/660 380/660 380/660 Retarder ratio 1:24.564 1:24.923 1:18.9 1:24.95 Scraper chain chain speed(m/s) 0.868 0.738 0.618 0.59 breaking force â?¥320 â?¥190 â?¥127.4 â?¥190 chain link spec.(mm) 18*64 14*50 14*40 14*50 scraper distance (mm) 1024 1000 800 700 middle groove dimension(mm) 1500*620*180 1200*420*180 1200*280*125 1200*3200*150 machine weight (KG) 17800 8581 3100 6400/6800 -

Product Series Motor Power (kW) Convey Capacity (t/h) Chain Speed (m/s) Chain Standard (mm) SGB-420/30(22) 30(22) 80 0.79 Φ14�50 SGB-520/40(30) 40(30) 120 0.79 Φ14�50 SGB-630/180 180 400 1.2 Φ22�86 Φ26�86 SGB-630/220 220 450 SGB-630/264 264 500 SGZ-730/320 320 600 0.98 Φ26�92 SGZ-730/320 400 700 SGZ-880/400 400 1500 0.95 Φ30�108 SGZ-880/500 500 1500 SGZ-764/750 750 1500 1.31 Φ34�126 SGZ-764/800 800 1500 Φ38�137 -

Parameter FU200 FU270 FU350 FU410 FU500 FU600 Groove Width(mm) 200 270 350 410 500 600 Capacity(m3/h) 10-30 20-60 35-100 50-130 70-200 100-270 Speed(m/min) 10-30 10-30 12-30 12-25 12-25 12-25 Chain Pitch(mm) 125 185 200 200 200 200 Distance(m) 8-50 8-50 8-50 8-50 10-40 10-40 Angle (°) �15 Power(Kw) 2.2-7.5 3-15 4-22 4-30 5.5-37 7.5-45 Installation Type Left/Right/Back Pack Type Drive System Chain Drive Granularity(mm) -

Chain plate conveyor Model HB50 HB60 Chain plate width (mm) 500 600 Conveying speed (m/min) 7-14 Conveying capacity (m³/h) 15-20 20-30 Conveying distance (m) General �40 Maximum 70 Max. Particle size (mm) 120 160 Inclined angle (°) �30 -

Type Z-17AW Z-20 Z-20AW Z-30AW ZQ-26 Loading Capacity (m3/h) 20-30 30-40 30-40 50-60 40-50 Capacity(m3) 0.17 0.2 0.2 0.3 0.26 Loading Width(M) 1.7 2.0 2.0 2.2 2.7 Rail Gauge(mm) 600mm (When the rail gauge is 750mm,762mm, pls mark in the order) Power Electric motor Electric motor Electric motor Electric motor wind motor Travel Power(kw) 10.5 10.5 10.5 1.5 10.5 Raising Hopper Power(kw) 10.5 10.5 13 15 15 Discharge Height(mm) 1250 1330 1360 1370 1250 Dimension(mm) Length (bucket down) L 2120 2480 2400 2620 2375 Width (pedal down) 1011 1210 1330 1300 1380 Height (bucket working) H2 1920 2180 2180 2260 2240 Height (bucket down) H1 1200 1518 1460 1545 1455 Weight(kg) 3760 3750 3700 4600 2700 -

Model Z20 Z30 load capacity 40cbm/h 60cbm/h bucket capacity 0.2cbm 0.3cbm loading Width 1900mm 2200-2500mm Discharge height (H) 1250mm 1300mm Dumping reach (S) 350mm 350mm Max operating height (H2) 1940mm 2250mm Travel speed 0.99m/s 0.99m/s motor model JI2-8 JI2-8 motor power 2x10.5kw 2x13kw track gauge 600mm (customized) 600mm (customized) overall dimension L (bucket is down) 2120mm 2590mm W 1070mm 1200mm H (bucket is down) 1305mm 1443mm machine weight 3400kg 4300kg -

Model Z20 Z30 load capacity 40cbm/h 60cbm/h bucket capacity 0.2cbm 0.3cbm loading Width 1900mm 2200-2500mm Discharge height (H) 1250mm 1300mm Dumping reach (S) 350mm 350mm Max operating height (H2) 1940mm 2250mm Travel speed 0.99m/s 0.99m/s motor model JI2-8 JI2-8 motor power 2x10.5kw 2x13kw track gauge 600mm (customized) 600mm (customized) overall dimension L (bucket is down) 2120mm 2590mm W 1070mm 1200mm H (bucket is down) 1305mm 1443mm machine weight 3400kg 4300kg -

Model Z-30W Loading capacity m3h 50-60 Bucket volume m3 0.3 Loading width m 2.7 Track gauge mm 600(note When the track gauge is 750 762 900) Power Electrical motor Walking power kW 15 Bucket power kW 15 Unloading height mm 1350 Machine Dimensions mm Length (when the bucket is Put down) 2620 Width (when the pedal is Put down) 1300 Height (when the bucket is Working) 2350 Height (when the bucket is Put down) 1570 Machine weight kg 4600 -

Type Z-20AW Loading Capacity (m3/h) 30-40 Capacity(m3) 0.2 Loading Width(M) 2.0 Power Electric motor Travel Power(kw) 10.5 Raising Hopper Power(kw) 13 Discharge Height(mm) 1360 Dimension(mm) Length (bucket down) L 2400 Width (pedal down) 1330 Height (bucket working) H2 2180 Height (bucket down) H1 1460 Weight(kg) 3700 -

Model ZQ-26 Bucket volume 0.26M3 Technique productivity 52-60M3/h Loading width 2500-2700mm Unload height 1250mm Unload distance 480mm Max. Air consumption 11.5-19M3/min Working pressure 5-6bar Gauge 600mm Wheel diameter 1000mm Length 2375 Width 1370 Height 1375 Motor 9+15kw Working speed about 0.79m/s Promoting speed 0.46-0.71m/s Weight 2700kg -

Model Engine Gear Speed(m/min) Pull Force(KN) Weight(Kg) ZJM3C R170F diesel engine 4 HP(Air cooled) (Slow) 4 30 100 (Fast) 8 No Lifting Reverse 4 No Lifting -

Model ZJM5B Engine HODNA GX390/186F Diesel Engine/YAMAHA MX360 Power 13HP,3600rpm/6.3KW,3600rpm/12HP,3600rpm Gear Forward Slow I Slow II Fast I Fast II Pull Force(KN) 50 30 15 9 Speed(m/min) 5 9 14 24 Weight(KG) 200 Dimension(mm) 1200x600x750 -

Parameter of 8 Tons Cable Winch With Diesel Engine Model Type Power Source Full force (KN) Speed of traction (m/min) weight (kg) ZJM8C R190 Diesel engine 10HP 80 4 200 40 7 no lifting 5 -

Parameter of 1 Ton Cable Powered Pulling Winch Model Type Power Source Rating traction force (KN) Speed of traction (m/min) weight (kg) ZJM1Q HONDA/YAMAHA 8 6 50 6 18 50 no lifting 15 50 -

Parameter of Double Capstan 5T Cable Pulling Winch Model/No. ZJM-5SQ Engine HONDA GX390 Power 13HP,3600rpm Suitable Wire Rope(mm) 15 Bottom diameter of Groove(mm) 240 No.Of Groove 6 Gear Forward Reverse Slow I Slow II Fast I Fast II Slow Fast Pull Force(KN) 50 30 13 10 No lifting No lifting Speed(m/min) 6 10 23 30 5 17 Weight(KG) 280 Dimension(mm) 1330*800*600 -

Parameter of ZJM Series Cable Push Pulling Machine Model Type ZJM-150 ZJM-180 Line pulling(KGS) 700 900 Pulling Speed(m/min) 8 6 Electric motor 1.1KW *2 1.5KW * 2 Oversize dimension 950*500*400 1020*590*400 Weight(KGS) 150 180-200 Cable diameter Dia. 30 - 180 mm Dia.30 - 200 mm Transimission I=45 I=60 Rubber sheet thickness 25mm 25mm -

Parameter of 1 Ton Fast Speed Motor Winch Model Type Power Source Rating traction force (KN) Speed of traction (m/min) weight (kg) ZJM1Q HONDA/YAMAHA 8 6 50 6 18 50 no lifting 15 50 -

Model ZM1200 Engine type Honda GX270 Power KW(hp) 6.9(9.0) Drive Manual winches Max width m(ft) 12(39) Max vibration thickness mm(in) 200(8) Section width m(ft) 2.54(8.3)/1.32(4.3)/0.71(2.3)

Isolated Chemical Oxygen Self-rescuer is individual breathing protection equipment which is made based on the principle of oxygen generation by chemicals. Miners use them to self-rescue when it is oxygen-poor or toxic gas threats their life in coal mine. Protection time(min):Medium labour intensity30min Sit quietly120min The oxygen concentration in breath:21% The Co2 concentration when exhale:3% The temperature in breath(°C)60°C Ventilation resistance(pa):196pa Production weight:1900g Production size:166*158*83mm

ItemZH15ZH30ZH45 other models available; ZYX-30,ZYX-45,ZYX60,ZL60 etc. Protection time>15min>30min>45min Suction pressure,1200Pa,1200Pa,1200Pa Temperature,60 Dimension138,89,185mm140,90,175mm100,93,133mm Weight1.6kg1.5kg2kg Valid Storage5years carry3years

ZYX60 Mining Self Contained Self Rescuer is in line with national standards of the miners and the ambulance crew carry reusable ambulance products, reasonable structure, reliable performance, easy to use. Model ZYX-60 Protection time Use time is 60 minutes Quantitative oxygen > 1.2L/min (l / min) Automatic supply oxygen > 60L/min (l / min) Manual oxygen supply > 60L/min (l / min) Volumetric 0.2 L (liter) Rated pressure 20Mpa (200 kg) Gas storage capacity > 40L (l) Automatic exhaust pressure 150-300Pa (Pa) Safety valve opening pressure 1Mpa CO2 absorbents mounted volume 255g Product quality (including CO2 absorber and oxygen) 1.36kg Dimensions 170mm * 75mm *140mm

Model ZYX45 Protect time â?¥40min Capacity of oxygen bottle 0.38L Oxygen storage capacity 80L Inspiratory oxygen concentration 25% Inhaled carbon dioxide concentration 2% Quantitative supply of oxygen 1.2L/min Manual supply of oxygen supply 60L/min Cylinder filling pressure 20Mpa Period of validity 3-5 years Outline dimensions 225*177*90mm weight 2.1kg

Model: ZYJ Water pressure : 0.1-0 .5 MPa Turbidity:

Automatic Portable Wall Plastering Machine is suitable for the construction & building industry ZM800-2A Plastering thickness2-28mm Plastering width80cm Plastering height0-5m Power supply2.2KW Capacity450-750m2/8hours Power220V/380V Dimensions1350*800*500mm Surface Very Smooth Level degree 2mm Perpendicularity degree 2mm Juncture device,Smoothing knifeYes

Model LYD-CY-3 Efficiency 500 m /8h thickness 2mm 30mm Size 1300850540mm Height Below 5m Voltage 220V / 380V Weight 180kg Wattle main motor:2.2kw1Vice motor 3.02

Model No. SRM4 Rendering Height(m) 4.2 Rendering Weight(mm) 800 Rendering Speed(m²/h) 60-70 Rendering Thickness(mm) 5-30 Power 0.75KW/380V/220V-50HZ/60HZ Electricity Phase Single / Three Dimension(mm) 800�650�550 Weight(Kg) 110 Usage Brick Wall, Block Wall Suitable Materials Cement Mortar,Ready Mix Mortar,Gypsum Mortar,Lime Mortar

Bending diameter o steel bar of round steel Round bar:6-50mm III class reinforced bar :6-42mm Speed of working disc 10r/mm Motor power 4KW Diameter of working disc 400mm

Product Name RBC-25 CE Approved Electric Rebar Cutter and Bender Brand Zhongyun Bender/Cutter Capacity #8 (1") grade 60 rebar Bending/Cutting Range 4-25mm, #8 (up to1") Machine Dimensions 500 x 450 x 790 mm (19.7"x17.7"x31.1") Machine Weight 136kg (300 lbs) Bending speed 5-7 seconds Voltage 220v / 110v Wattage 1600 w /1700 w Bending Angle 0-180 degrees Standard Equipment Roller Kit, Manual Shipping Weight 167kg (368 lbs) Shipping Dimension 570 *480 *980 mm (22.5"x18.9"x38.6") Warranty 12 Month Parts Package One Pct /Metal Box/Card board Ctn

SPECIFICATIONS RB-25 Max. Bending Capacity 25mm / 1 Min. Bending Capacity 6mm Voltage 220/110V Bending Angle 0-180° Power Spply Single Phase Wattage 1600w/1700w(2.2HP) Machine Weight 91kg Goss Weight 109kg Machine Size 450*500*440mm Packing material metal box Packing Size 500*555*505mm Certification CE ROHS

Place of Origin: Shandong China (Mainland) Brand Name: zhongyun Model Number: RC-16 Type: REBAR BENDER Voltage: 220/110V Wattage: 800/900W Bending speed: 5.0 s Max.diameter: 16mm Min.diameter: 4mm Gross weight: 16.5kg Machine weight: 15kg Certificate CE ROHS

Name: Portable Electric Hydraulic Rebar Bender Type: NRB-32 Voltage: 220V Wattage: 1350W Gross weight: 32KG Net weight: 24KG Bending speed: 5.0-8.0S Max.rebar: 32MM Min.rebar: 4MM Carton size: 760*290*220MM Machine size: 560*260*200MM Bend angle: 0-130 Package: One Pc /Metal Box/Cardboard Ctn Certificate: CE ROHS

Single processing capacity 4-12mm Dual processing capacity 4-8 mm Bending Angle 180 Central axis diameter 18-25mm Maximum traction speed 75-90m/min Maximum bending speed 1000/SEC Exact length 1mm Angle precise 1 average power consumption 3-5 kw/h number of processing 2 Pneumatic pressure 0.2-0.6 Mpa Equipment power 23.5kw/380V/60Hz size/Weight 3100*850*1580 mm/1160 kg

Items parameter Traction servo motor total power 7 KW spindle speed 1800 r/min Processing scope single line 4-12 mm diplonema 4-8 mm Maximum draught speed 90-100 m/min material-feeding accuracy ±1 mm Processing Angle tolerance ±1° Length scope 60-1200 mm processing capacity 1100-1200 Pic/H Pressure of Hydraulic pump station 0.8-1.0 MPa OTR operation temperature range -5-50 C Whole weight 2.0-2.2 ton overall dimension 3700*1600*1000 mm hydraulic pressure pimping station power 7.5 KW Rotate speed 1500 r/min General power of equipment 15 KW power consumption per hour 10° Output per hour 2200 unit Payment T/T;western union MOQ 1set

Main Technical Parameter Model CM-2A Portable Concrete Mixer Charging Volume 260L 300L 350L 400L 500L Reclaiming Volume 230L 270L 320L 370L 470L Productivity 6-10m3/h 8-12m3/h 10-14m3/h 12-16m3/h 16-18m3/h Speed of Mixing Drum 30r/min Power Type Diesel Engine/Gasoline Engine/Electric Motor Engine Power 4HP 6HP Drum Thickness 2.75-3.75mm Transmission Way Gear Wheel Type of The Tires 4.00-8 Overall Dimension(LWHmm) 1700* 970*1600 1900*1070*1700 1900*1070*1750 1900Ã?1070Ã?1750 2000*1090*1115 Weight(kg) 300 320 330 340 400 Loading Plan 14 sets Per20gp, 28 sets Per 40HC for Concrete Mixer 12sets/20GP,26sets/40HC for Concrete Mixer

JQ350 Small Mini Pan Type Concrete Mixer Machine Features 1. reasonable machine design, performance optimization; 2. easy maintenance; 3. solid and reliable, the life of plants; 4. mixing quality, high efficiency 5. easy to operate, fast discharge 6. low energy consumption, low noise Model JQ350 Discharging Capacity 350L Charging Capacity 500L Production Capacity 5-8 m3/h Max Aggregate Diameter 40mm Stirring Vane Rev Speed 19r/min Mixer power Power 4kw Pump Power 1.1 kw

Model 350Y Capacity 3.5ft³ Motor 3/4hp, 115v, 60Hz, single phase Drum material polyethylene, anti-UV Mixing blade 3 steel blades Frame steel Bearings sealed ball bearing Wheels flat free tire 14" x 2.50 to 8 Dimensions 50 *28 *40" Net weight 50kgs Gross weight 56kgs

1. Capacity 180L 2. Motor power 2.2KW 3. Rotation speed 70r/min 4. Mixing capacity 6m3/h 5. Weight 200kg 6. Feeding height 980 mm 7. Our size dia *height 900 * 1146(mm * mm)

Model JS500 Discharge volume 500L Charging volume 800L Theoretical capacity 25m3 Aggregate sizes 60/80mm Working circle 60s Mixing blade Speed 35r/min Quantity 27 Mixing motor Model Y180M-4 Power 18.5 kw Lifting motor Model YEZ132S-4 Power 5.5 kw Pump motor Model 50DWB20-8A Power 0.75 kw Weight 1500kg Dimensions (L x W x H) 3030*2300*2680 mm

HMR60 Concrete trowel machine is widely used in surface of concrete raised paste and trowel and smooth out in high-standard workshop, warehouse, parking lot, square, airport and frame-style building. The efficiency of this power trowel machine is 10 times higher than the manual work. The max rev is up to 135r.p.m. Model HMR60 Engine Honda GX160, Robin EY20, Lifan 168F Engine type Air-cooled, Single cylinder, Four stroke Engine Engine power 4.0-5.5HP Working diameter 600mm Rotation speed of blade 70-130rpm Package size (mm) 720*670*790 Net weight 65kgs

HMR80 Walk-behind Power Trowel Machine is used to lift, vibrate, slide and towel road surfaces. Using the machine with electric motor for casting concrete floors gives the finished product a professionally new look. This Machine is also used for both floating and finishing concrete floors. Compared to hand trowels, which significantly increase the working efficiency. Model HMR80 Engine Honda GX160, Robin EY20, Lifan 168F Engine type Air-cooled, Single cylinder, Four stroke Engine Engine power 5.0-5.5HP Working diameter 780mm Rotation speed of blade 70-130rpm Package size (mm) 900*900*750 Net weight 70kgs

Features : 1. Heavy-duty gearbox, excellent performance and durability. 2. Emergency switch can automatically cut engine power, to ensure operator safety. 3. Armrest can be adjusted to accommodate different height of the operator. 4.Balanced blade design makes the machine more stable. Model HMR100 Engine Honda GX160, Robin EY20, Lifan 168F Engine type Air-cooled, Single cylinder, Four stroke Engine Engine power 5.0-5.5HP Working diameter 960mm Rotation speed of blade 70-130rpm Package size (mm) 1120*1120*800 Net weight 93kgs

Model ZM-90 Power Honda GX690 24HP Blade size 310*150*2mm Blade quantity 10 Blade pitch 65-120mm Disc diameter 900mm Dimension 1900*950*1180mm Total weight 430kg Rotational speed 140r/min-180r/min Operating mode Driving type Starting system Electric start Fuel Tank Capacity 20L Lubricating oil volume 1.5L Engine type Two cylinder oil air-cooled Automatic water spray Yes Construction lighting Yes Walking wheels Lift type

Model ZM-100 Power Honda GX690 24HP Blade size 350*150*2mm Blade quantity 10 Blade pitch 65-120mm Disc diameter 1000mm Dimension 2080*1050*1180mm Total weight 450kg Rotational speed 140r/min-180r/min Operating mode Driving type Starting system Electric start Fuel Tank Capacity 20L Lubricating oil volume 1.5L Engine type Two cylinder oil air-cooled Automatic water spray Yes Construction lighting Yes Walking wheels Lift type

Voltage 220V/110V Wattage 850W/1170W Gross weight 32kg Machine weight 24.5kg Cutting speed 5 s Max rebar 25MM Min rebar 4MM Package One Pc /Metal Box/Cardboard Ctn Carton Size 555*205*327MM Machine Size 480*150*255MM Certificate CE ROHS

Model GQ50 Cutting diameter Round steel :6-50mm Class of reinforced steel bar :6-40mm Flat steel :80*15mm Angle steel : 63*63mm Square steel :40*40mm Cutting frequency : 28times/min Motor power 4kw Voltage 380V/50HZ Dimension 1370*550*880mm N.W: 500KGS -

Model GQ40B Blade 26mm Plain carbon steel �Φ40mm Deformed steel bar �Φ32mm Square steel bar �32mm*32mm steel angle bar �50mm*50mm steel flat bar �70mm*15mm Motor power 3/2.2KW motor speed 2890r/min Voltage 380V/220V Weight 450KG Size 1250*500*730mm G.W.(KGS) 380 N.W.(KGS) 347 -

1 )Famous motor and generator, excellent performance, start easily. 2) metal halide lamp has long service life. 3) Anti-fall, safe and solid. 4) Hand-operated winch, lockable at any moment. 5 )Elevating frame is made of stsainless steel square pipe; 6) Elevating frame can rotate, east for light waving, overturn to intake,transport and store. 7) Plastic treated, anti-rust, anti-corrosion and beautiful. Light Tower Model MO-400A MO-1000A Generator EC2500CX/ 3GF-LED EC4000CX/ 3GF-LED Type Air cooled, 4stroke, OHV gasoline engine Air cooled, 4stroke, single cylinder direct injection type diesel engine Generator Types Single-phase alternator Single-phase alternator Rated Power 2.0kw 3.0kw Rated Voltage 220V 220V Continuous working time (hour) 13hr 13hr Oil Tank 15L/12.5L 25L/12.5L Power*lamp 400W*2 1000W*2 Stanchion Lamp frame 3 sections 4 sections Elevating height 1800-3800mm 1800-4600mm Anti-slope -

Mast Generator extended length 4.5m rated power 50Hz 3kw retracted length 1.8m Insulation Class H anti-wind capacity â?¤6 working temps -5~40â?? Lights output power 3KW lamp two halide fuel tank capacity 15L wattage 500W per lamp runtime before about 13h working life 3000h wheels of trailer 4pcs -

Power of Lamp 4*1000W Generator Power 6KW Elevation Height 700CM By Hand-operated Working Time 42-45H Anti-wind Capacity less than 6-G Frequency 60HZ Engine Brand KIPOR Power Rating 6KVA Luminous Flux 440000LM Insulation Grade H Generator Brand SENCI Model Number FHZM-T Model Number FHZM-T SHIPPING SIZE 408*160*175CM -

Model Lamp Solar Panel Battery Mast Trailer MO-1200D-L 4*60W/4*100W/6*100W 4 * 330W 6*150AH/8*150AH/8*200AH 6/9M Dual axle MOS-2400A-L 4*60W/4*100W/6*100W 8 *330W 12*150AH/16*150AH 6/9M Dual axle MOG-600-A 4*60W/4*100W/6*100W 8 *330W 12*150AH/16*150AH 6/9M Dual axle -

Solar Power Light Tower Axle Single Led Lighting Tower Tire And Rim Size MAXXIS A/T R15 Ecnomic Light Tower Outrigger Manual Tower Light Tow Hitch 50mm Ball 4412LBS Mast Raise/Extension Manual Environmental Tower Light Tilt Manual -

Engine:6.5HP, gasoline Net weight:180KG Transmission:3 forward+1 reverse Brake parking: mechanical Box length:900mm Box width:660mm Box depth:285mm Measurement: 1510*667*965mm -

Model JS-37T Machine size 270 mm * 65 mm * 195 mm The machine weighs 970g Battery type lithium ion batteries Battery charging time quick charge 40 minutes, 1.5 hours slow filling Rated voltage 10.8V Applicable scope of steel strapping 8 mm - 34 mm Coil wire diameter 0.8mm coil wire length more than 110 m Knot wire length 40 cm and above Knot the required time 0.8 seconds at a time Knot number per charge 1000 times Each machine distribution battery number 1 (2) or optional Each machine delivery charger number 1 -

Model: RTM-21 Tying Diameter: 21mm Time Of Making A Knot: 0.8 Seconds Voltage: DC9.6V Weight: 2.15kg Turns Per Tie: 2 Turns/ 3 Turns Ties Per Coil: Approx. 260 Ties(2 Turns) Ties Per Charge: 4-5 Coils Length Of Wire For Tying: 380mm/2 Turns ( 510mm/3 Turns ) Dimension(L)X(W)X(H): 268X100X296mm -

Model BW450 mud pump Max. flow 450 L/min Max. pressure 2 Mpa Engine power 18.5kw Suction pipe diameter 89mm Discharge pipe diameter 51mm Weight 540kg Hole depth

Maximum flow 600L / min Greatest pressure 6Mpa Driving power 30KW Suction pipe diameter 89mm Drain pipe diameter 51mm Drill hole depth (m) â?¤800 Dimensions (mm) 1000 Ã? 995 Ã? 650 Total Weight 700kg -

Model BW850/5 water well mud suction pump Type Horizontal double cylinder reciprocating double action piston pump Cylinder diameter (mm) 260 Stroke (mm) 66 Pump speed (times/min) 140 130 95 Flow (l/min) 850 600 350 Pressure (Mpa) 5 6 8 Power (Kw) 90 Shape size (mm) 3018*1120*2050 Weight (kg) 3100

Model GLP-511 Working flow 5m3/h By size -

Maximum Working Pressure 3MPa Electric Motor Power 7.5Kw Hopper Capacity 80L Weight 320Kg Power 5.5Kw Conveying Flow 3m3/h Convey Speed 30m Max.Conveying Dist. 50m Max.Particle Size 4mm

Model N1 Power 0.75kw voltage 220/380v Flux 0-6 L/min Transfer meter. Level 15m Transfer meter vertical 10m Speed of rotate 300rpm Hoper volume 15L Weight 100KG Size 700*400*850mm -

the theoretical max conveying capacity 3m^3/h transportation distance 50m through partical size

Voltage 220V/110V Wattage 690W/760W Gross weight 13Kg Machine weight 8Kg Cutting speed 2.5-3.0 s Max rebar 16MM Min rebar 4MM Package One Pc /Metal Box/Cardboard Ctn Carton Size 510*230*150MM Machine Size 460*270*115MM Certificate CE ROHS -

RC-20 Portable Rebar Cutting Machine is of light weight, small size, easy to carry, easy to operate, cutting process does not produce sparks, dust, no odor. Mainly used to cut steel bars used in construction, such as rebar. Round. Steel bars. Screws, etc. Voltage 220V/110V Wattage 830W/900W Gross weight 17.5kg Machine weight 13kg Cutting speed 3.0-3.5 s Max rebar 20MM Min rebar 4MM Package One Pc /Metal Box/Cardboard Ctn Carton Size 460*160*270mm Machine Size 410*115*220mm Certificate CE ROHS

Item less than 24kg/m rails 30kg/m rail More than 30kg/m rail Max. Straightening Capacity 294KN 410KN 549KN Rated Straightening Capacity 270KN 350KN 500KN Piston Stroke 70mm 70mm 70mm Weight 30kg 50kg 70kg overall size 730x450x165mm 900,500,175mm 990,555,183mm

Critical speed(m/s) 1.25 2 2.5 3 3.5 4 Braking power(J) 750 800 830 874 900 930 Resistance work(J) No more than35 no more than 40 no more than 45 Lift height(mm) no more than 8

TDY203 short retarder has great braking power, in line with department standard; no mushroom head, not topping; adapt to all types of new and old lines; collision and derailment never happened. It requires no external energy and external control. By the speed and pressure valves and other hydraulic valve structure automatically to judge the speed of the humping vehicles, and act in accordance with different speeds, so as to achieve automatic control humping vehicles speed.

Critical speed(m/s) 1.25 2 2.5 3 3.5 4 Braking power(J) 750 800 830 874 900 930 Resistance work(J) No more than35 No more than 35 No more than 40 No more than 40 No more than 45 No more than 45 Lift height(mm) No more than 8 No more than 8 No more than 8 No more than 8 No more than 8 No more than 8

Mode Size mm AXBXCXD Weight(kg/m) Length(m) QU70 120x120x70x28 52.80 9/9.5/1010.5/11/11.512/12..5m QU80 130x130x80x32 63.69 9/9.5/1010.5/11/11.512/12..5m QU100 150x150x100x38 88.96 9/9.5/1010.5/11/11.512/12..5m QU120 170x170x120x44 118.10 9/9.5/1010.5/11/11.512/12..5m

Mode Size mm AXBXCXD Weight(kg/m) Length(m) QU70 120x120x70x28 52.80 9/9.5/1010.5/11/11.512/12..5m QU80 130x130x80x32 63.69 9/9.5/1010.5/11/11.512/12..5m QU100 150x150x100x38 88.96 9/9.5/1010.5/11/11.512/12..5m

The list of China Coal Light Steel Rails Name of Commodity Specification Materials (Steel Grade) Standard of Products Theory Weight (kgs/M) Length of Dimension (M) Packed In Bundle With Iron Wire (pcs/bundle) Light Rail 4kgs/m Q235 Q/YYG001-2008 4kgs/m 6,8,9,10 75 8kgs/m Q235 Q/YYG001-2008 8.42kgs/m 55 12kgs/m Q235 GB11264-89 12.2kgs/m 36 15kgs/m Q235/55Q/50Q GB11264-89 15.2kgs/m 28 18kgs/m Q235/55Q/50Q YB222-63 18.06kgs/m 21 22kgs/m Q235/55Q/50Q GB11264-89 22.3kgs/m 21 24kgs/m Q235/55Q/50Q Q/YYG001-2008 24.46kgs/m 21 30kgs/m Q235/55Q/50Q GB11264-89 30.1kgs/m 15

Normally, steel rail is devide into light rail ,heavy rail and crane rail 1)Light rails: 6kg/m,9kg/m,12kg/m,15kg/m,18kg/m,22kg/m, 24k/mg, 30kg/m Material: Q235B / 50Q / 55Q Length of each piece: 6m~12m Executive standard: refer to GB11264-89 2)Heavy rails: 38kg/m, 43kg/m, 50kg/m, 60kg/m Material: U71Mn / 50Mn / 44Mn Length of each piece: 12m,12.5m Executive standard: refer to GB2585-2007 3)Crane rails: QU70,QU80,QU100,QU120 Material: U71Mn Length of each piece: 12m,12.5m Executive standard: refer to GB3426-82

The list of China Coal Steel Name of Commodity Specificaton Materials (Steel Grade) Standard of Products Theory Weight (kgs/M) Length of Dimension (M) Packed In Bundle With Iron Wire (pcs/bundle) Light Rail 4kgs/m Q235 Q/YYG001-2008 4kgs/m 6,8,9,10 75 8kgs/m Q235 Q/YYG001-2008 8.42kgs/m 55 12kgs/m Q235 GB11264-89 12.2kgs/m 36 15kgs/m Q235/55Q/50Q GB11264-89 15.2kgs/m 28 18kgs/m Q235/55Q/50Q YB222-63 18.06kgs/m 21 22kgs/m Q235/55Q/50Q GB11264-89 22.3kgs/m 21 24kgs/m Q235/55Q/50Q Q/YYG001-2008 24.46kgs/m 21 30kgs/m Q235/55Q/50Q GB11264-89 30.1kgs/m 15

Model Head width Rail height Web Thickness Bottom Width Weight Material Rail length 38kg/m 68mm 134mm 13mm 114mm 38.733 kg/m U71Mn/U71 /45Mn 12,12.5m 43kg/m 70mm 140mm 14.5mm 114mm 44.653 kg/m U71Mn/U71 /45Mn 12,12.5m 50kg/m 70mm 152mm 15.5mm 132mm 51.514 kg/m U71Mn/U71 /45Mn 12,12.5m

Item No. Description Specification Material 1 Fish Bolt 22135, 24135, 24145 Q235 2 High-strength Fish Bolt 22135, 24135, 24145 C45 3 Insulated Bolt 22160, 24160, 24170 C45 4 T type bolt M24x110 Q235 5 Flat Washer 62550 Q235 6 Spring Washer 208, 248, 268 7 Double Spring Washer 268 8 Screw Spike M22x185, M24x195 Q235 9 Square head screw spike 22x145, 22x155, 22x165 Q235A 10 Hexagon screw spike 22x145, 22x155, 22x165, 22x185, 22x195 Q235A 11 Dog Spike 16165 12 Gauge apron 10#, 13#, 14#, 20# Q235 13 Antiseptic gauge apron 10# Q235 14 Steel Tie plate/ base plate QT450-10 15 Rail anchor QT450-10, Q235A, QT400-15 16 Rubber tie plate P43, P50, P60 Rubber 17 Elastic rail clip A,B Type 60Si2Mn 18 SKL serious Type 60Si2Cr, 38Si7 19 G Type 60Si2MnA 20 W Type 21 Antiseptic elastic rail clip B Type 60Si2MnA 22 Nylon apron block V type, 0-4#, 2-6# polyamide 66 23 Insulated Rail Gauge Rod 32, 36 24 Rail Gauge Rod 32, 36 25 Fish plate 43kg, 50kg, 60kg, 75kg B7. 45# BS60, BS75R, BS80A, BS90A B6, B7 Insulated fish plate (43, 50, 60, 75).. B6, B7 UIC60, UIC54 50#, 45#

Project number Name Specifications Material Science 1 Fishbolt 22,135/24,135/ 24,145 Q235 2 High strength bolt 22,135/24,135/ 24,145 C45 3 Insulated bolt 22,160/24,160/ 24,170 C45 5 Flat washer 6,25,50 Q235 6 Spring washer 20,8/24, 8/26 , 8 7 Spike 16,165 8 Screw spike M22,185 M24,195 Q235 9 Steel plate / floor QT450-10 10 Fish plate 43Kg/50Kg/60Kg/75Kg B7/45# BS60,BS75R,BS80A BS90A B6/B7 11 Fish plate insulation 43Kg/50Kg/60Kg/75Kg B6/B7 UIC60 UIC54 50#/45#

BS-500 Series Steel Sleepers SIZE STANDARD MATERIAL LENGTH BS75A BS 500-2000 SAE1522 ST52.3 20MnK SS490Q255A 1830mm 1900mm 2000mm

Type Reinforcing-bar Concrete grade Section height Section width Base area (cm2) Weight (kg) Length (cm) Sub-rail Middle Ending Sub-rail Middle I 36 dia.3 C48 20.2 16.5 29.45 27.5 25 6588 251 250 II 44 dia.3,4 dia.10 C58 20.2 16.5 29.45 27.5 25 6588 251 250 III 10 dia.7, 8 dia7 C60 23.0 18.5 30.0 28.0 7720 320 260

1.Normal sleepers Width 220mm; thickness 160mm; length 2500mm; 2.Turnout sleepers (Normal) Width 220mm; thickness 160mm; length 2600 ~ 4850mm, with 150mm carry a total of 16 lengths; 3.Turnout sleepers (Standard) Width 240mm; thickness 160mm; length 2600 ~ 4800mm, with 200mm carry a total of 12 lengths; 4.Bridge sleepers Width 220mm; thickness 240,260,280,300 mm; length 3000mm.

Product Name Agriculture UAV Wheelbase 1350mm Working Speed 5-10m/s Max Take off Weight 22kg Max Payload 12Kg Working Altitude 0.5-5m Payload 12L Wind Risistance 5Level Duration of Flight 10-15min Working Temperature -15-50 Spray Width 4-6m(adjustable) Nozzle Type Pressure Nozzle Number of Nozzles 2 Battery 2 Pcs 12000m Ah Li-Po batteries Color Yellow Logo DIGITAL EAGLE

1. Simple operation and low failure. 2. Spray width: 3.5-4.5 meters. 3, GPS positioning: There is autonomous take-off function (when the plane takes off, just push the throttle can be). The height can be set, and when the voltage is too low, there is an automatic alarm function. 4, each spray area: 20-40 acres during the day, 10-20 acres at night, 1 minute for 1 minute Eight-rotor agricultural drone technical indicators Dimensions (length * width * height) 2110 * 2110 * 800mm Aircraft weight 11KG Maximum takeoff weight 30KG Pesticide container capacity 10L Boom length 220cm Body Material Carbon Fiber & Aluminum Alloy Charger High-power lithium balance charging device Spraying system, medicine box, diffusion spray system, booster pump Operating temperature -10°C-40°C Lithium battery life 300 times charge and discharge Maximum payload (5-20) KG (±5%) Lithium polymer power battery 22.2V/16000mA / battery life 10min Working speed 3-8m/s (wind speed 2-3) Relative flight height 1-3 meters from crops (depending on different crops) Spray width (6 0.3L/min nozzles, 2.2 meters long spray tube) 2-4 meters (downwind or upwind, wind speed 2-3) Spray flow rate 1-1.2L/min (6 nozzles) High-concentration pesticide consumption 0.5-1.0L/mu (depending on different crops) Single machine spraying operation efficiency of 300 mu / day (depending on the actual operation of the flying hand)

Model Volume (m) Load (T) Gauge (mm) Wheel Base (mm) Wheel Diameter (mm) Traction (KN) Traction Height (mm) Overall Size (L*W*H) KFU0.55-6 0.55 1.3 600 500 300 60 320 1552*850*1150 KFU0.75-6 0.75 1.88 600 600 300 60 320 1700*980*1250 KFU1.0-6 1.0 2 600 600 300 60 320 1910*1070*130 KFU1.2-6 1.2 3 600 700 300 60 320 2228*1070*1320

mine material car model MLC2-6 MLC3-6 MLC5-6 MLC5(3)-9 MLC3-9 loadage(t) 2 3 5 5 3 track gauge(mm) 600 600 600 900 900 contour dimension(mm) 2000*880*1150 1050*1200*1200 3450*1200*1200 3450*1230*1200 2100*1150*1300 wheel base(mm) 550 750 1100 1100 900 wheel diameter 300 300 350 350 350 heigth of towing attachment(mm) 320 320 320 320 320 allowed traction(kn) 60 60 60 60 60 overall weight(kg) 520 520 920 940 790

Model MDC3.3-6 MDCC3.3-6 MDC5.5-9 MDCC5.5-6 Volume m3 3.3 3.3 5.5 5.5 Capacity ( t) 3 3 5 5 Max capacity (t) 5.3 5.3 8.8 8.8 Gauge mm 600 600 900 600 Overall size (mm) Length 3450 -3680 4200 -5050 Width 1200 1200 1520 1360 Height 1400 1400 1550 1600 Wheel base mm 1100 1100 1350 1600 Dia. Of wheel mm 350 350 400 400 Traction height mm 320 320 430 430 Rated traction KN 60 60 60 60 Load angle 50° 55° 50° 55° Weight kg,1700,1700,3000,3000

Model Volume (m) Load (T) Gauge (mm) Wheel Base (mm) Wheel Diameter (mm) Traction (KN) Traction Height (mm) Overall Size (L*W*H) KC1.2-6 1.2 3 600 600 300 60 320 2100*1050*1200 KC1.6-6A 1.6 4 600 800 350 60 360 2500*1200*1300 KC2-6A 2 5 600 1000 400 60 385 3000*1250*1300 KC2.5-6A 2.5 6.25 600 1100 400 60 385 3500*1250*1300 KC3-6 3 600 1400 350 60 420 3600*1350*1335

Model Volume Carrying Capacity Track Gauge Length Width Height m3 T G mm mm mm MCC0.7-6 0.7 1.75 600 1650 980 1050 MCC1.2-6 1.2 3 600 1900 1050 1200 MCC1.6-6 1.6 4 600 2500 1200 1300 MCC2-6 2 5 600 3000 1250 1300 MCC2-7 2 5 762 3000 1250 1300 MCC2.5-6 2.5 6.25 600 3500 1250 1300 MCC2.5-7 2.5 6.25 762 3500 1250 1300 MCC4-7 4 10 762 3900 1400 1650 MCC4-9 4 10 900 3900 1400 1650 Specification and parameter of dumping mine car Model Wheelbase Wheel Diameter Height of Traction Traction Unloading Angle Own Weight mm mm mm KN Kg MCC0.7-6 600 300 320 50 40 750 MCC1.2-6 600 300 320 50 40 1000 MCC1.6-6 800 350 320 60 40 1670 MCC2-6 1000 400 320 60 40 1830 MCC2-7 1000 400 320 60 40 1880 MCC2.5-6 1100 400 320 60 40 2510 MCC2.5-7 1100 400 320 60 40 2510 MCC4-7 1300 450 430 60 40 3230 MCC4-9 1300 450 430 60 40 3300

Model Parameter JH-5 JH-8 JH-14 JH-20 JH-30 Steel wire rope average static tension (KN) 50 80 140 200 300 Steel wire rope (m/s) average speed 0.17 0.12 0.115 0.118 0.13 Drum diameter* width (mm) 276* 372 280* 230 400* 317 430* 530 550*560 rope capacity (m) 80 100 130 170 220 Steel wire rope diameter 15.5 17 21.5 24.5 30 construction 6* 19 6* 19 6* 19 6* 19 6* 19 nominal extension strength (M pa) 1550 1550 1550 1550 1570 Explosion proof motor Model YBJ7.5-4 YBK2-160M-6 YBK2-200L1-6 YBK2-200L2-6 YBK2-280S-4 Power (KW) 7.5 7.5 18.5 22 45 Voltage (V) 380/660 380/660 380/660 380/660 380/660 Rotate speed (r/min) 1450 970 970 970 980 Overall size: length* width* height 1450* 512* 515 1550* 530* 570 1955* 680* 815 2560* 968* 797 3300*1077*1034 Winch weight (including motor) 620 650 1350 2600 4460

Model JD-0.5 JD-0.75 JD-1 JD-1.6 JD-4 Traction Force KN 7.5 7.5 10 17.6 30 Average Speed m/s 0.71 0.71 0.78 1.4 1.44 Dia of Wire Rope mm 9.3 9.3 12.5 15 20 Drum Size mm 200300 200300 224304 310400 620580 Rope Capacity m 250 250 400 440 480 Total Reduction Ratio 34.81 34.81 41 32.5 31.8 Motor Type YB132S-4-B5 YBJ-11.4 YBJ45-4 YBJ40-4 YB2-132S-4 Motor Power KW 5.5 11.4 25 40 5.5 Motor Rev Rev/min 1440 1460 1470 1470 1440 Motor Voltage V 380/660 380/660V 380/660V 380/660V 380/660V Di mention mm LWH 1085730 697 1085730 697 1073766 727 14481255 1260 19002350 1370 Weight KG 400 400 578 1370 2800

ModelMaximumRope capacityrope speed (m/min)wire rope diameterMotorOverall size (mm)Weight hoisting capacity (KN)(m)Fast speedslow speed(mm)power (KW)voltage (V)(kg) JZ-5/40050400632311380/440237519703140 1340 JZ-10/600100600633122380/440303725706250 1770 JZ-10/800100800633122380/440334229066500 1825 JZ-16/800160800634030380/4403358320011480 2240 JZ-16/10001601000634036380/4403508320011700 2240 JZ-25/13002501300635245380/4403827262314678 2500 JZ-40/13004001300636575380/4404596421825000 2975

The allowing impact speed of the vehicle 15-25km/h The center of the buffer head to the rail surface height 850mm Acceptable impact speed 10km/h,20km/h,25km/h,30km/h For the subway,light rail and other vehicles 500mm,660mm,720mm,824mm For the China railway high-speed and bullet train 1050mm

Model No. ZM-22 ZM-40 ZM-50 Max Tying Diameter 21mm 40mm 50mm Time of Making a Knot 0.8 seconds 0.8 seconds 1.0 seconds Voltage DC9.6V DC9.6V DC9.6V Weight 2.15kgs 2.2kgs 2.25KGS Turns per Tie 2 turns/3turns 2turns/3turns 3turns/4turns Ties per Coil Approx. 260ties(2turns) Approx.160ties(2turns) Approx. 100 ties(3 turns) Ties per Charge 4-5 Coils 6-7 Coils 7-8 Coils -

Model KW0041 Applicable rebar Sizes 8-68mm Wire Diameter 1.5mm Time of Making a knot 1.2 seconds Voltage DC9.6V Weight 3.3kgs Turns per tie 1turn Ties per coil Approx 140ties/1 turn Ties per charge 5coils/700 ties Wire Length Per Coil 28m Length of Wire for Tying 100-220mm/1turn Machine Size(L*W*H)(mm) 330mm*310mm*80mm -

FEATURE: 1 Max. Tying Knots: more than1200knots on a single charge 2 Typing time: 0.8second/knot 3 The number of the knot can be select to be 2 turns or 3 turns 4 Packing precast concrete products 5 Precast steel or mental tubing packing in architecture engineering scen 6 Rebar tying machine Widely used in construction industry 7 Rebar tying machine ( KP-400A ) conforms to 89/336/EEC Electromagnetism Compatible, 73/23/EEC Low Voltage and 98/37/EC Machinery Requirement of ECC Instruction. 8 Rebar tying machine (KP-400A) is hand-held machine used to pack rebars quickly. 9 Automatic rebar tying machine by iwiss made is a miniature motor tool possesses the trait of safety and credibility. Rebar Tying Machine Model KP-400A Exerior size(mm) 290Ã?100Ã?277 Machine weight(Kg) 2.1 Motor voltage(v) 9.6 Max tying diameter(mm) 40 -

Model WL-210 Max Tying Diameter 21mm Time of Making a Knot 0.8 s Battery Type 9.6V Ni-MH 3000mAh Charge time 1 hour quick charger GW of Machine 2.15kgs Max. Number of Tying Knots 1200ties (one Ni-MH battery) Wire Type galvanized steel wire, Annealed steel wire Wire 0.8mm Turns per Tie 2 turns/3turns Ties per Coil Approx. 260ties(2turns) Ties per Charge 4-5 Coils -

Pump Type Horizontal Type of action Double Acting cylinders 1 Cylinder diameter (mm) 95 Stroke (mm) 85 Number of reciprocations (times / minute) 165 Displacement (liters / min) 160 Working pressure (MPa) 1.6 Transmission shaft speed (r / min) 951 V - belt pulley diameter (mm) 270 V-belt pulley type and slot number B-type � 3 slot Transmission power (kW) 7.5 Diameter of suction pipe (mm) ø45 Drain pipe diameter (mm) ø38 Overall dimensions (L* W* H) (mm) 1110* 800*950 Weight (not including power machine) (kg) 136 Motor Y132M-4 Power 7.5KW Speed 1440r / min Diesel Engine R180 Power 5.67KW Diesel Engine Speed 2600r / min -

The BW320 Triplex Single Acting Reciprocating Piston Mud Pump is a horizontal single-acting reciprocating mud pump with three cylinders. It has two cylinder diameters, four changeable gear speeds and eight flows can be chosen. It can support for the hydraulic impact drilling for the hole depth within 1000 meters, the screw drilling or turbine drilling for the hole depth within 1500 meters and geological core drilling for the hole depth of 2500 meters. Model BW320 Type Horizontal, Single-acting, Reciprocating, No. of Cylinders 3 Stroke 110mm Cylinder Diameter 80mm 60mm

Model SP10N Voltage 220V Power 3kw Displacement volume 13L/min Delivery pressure 30bar Delivery distance 15m Delivery height 15m Length of spraying tube 25m Hopper capacity 50L Feeding mode Blender mixing materials Total weight 90kg Packing Wooden case -

Engine speed50Hz 3000 rpm AlternatorHONDA EC4000 Fule tank capacity26L Prime fuel consumption at 100% loadâ?¤374g/Kw.h Working hours16 Control systermDigital control pannel Power outlet3 manual Trailer Stabilier Support4 manual Tire SizeDiameter=65cm Anti-wind capacityâ?¤6 BrakesManual Dimension & Weight Retracted Dimension 1560mm 680mm 980mm Container load (20FT / 40FT)15/ 30(At least) Net weight200kg -

Engine:6.5HP, gasoline Net weight:180KG Transmission:3 forward+1 reverse Brake parking: mechanical Box length:900mm Box width:660mm Box depth:285mm Measurement: 1510x667x965mm -

Model WL-400 Max Tying Diameter 40mm Time of Making a Knot 0.8 seconds Battery Type 9.6V Ni-MH 3000mAh Charge time 1 hour quick charger GW of Machine 2.1kgs Max. No. Of Tying Knots 1200ties (one Ni-MH battery) Wire Type galvanized steel wire, Annealed steel wire Wire Size 0.8mm diameter Packing Info. . 1Pc of Rebar Tying Machine . 2Pcs of Battery . 1Pc of Charger . 4Pcs of Steel Wire Spool . 1pc of Inner Hexagon Spanner . 1pc of Sharp Nose Pliers Packing Size: 408*162*418mm GW of one set: 7.5kg Certificate: CE -

1. Match light are multiplexed lines. 800Hz telephone impedance is 800Ω ± 20%. 2 .Through two telephones on the same model, in less than 75db audio noise conditions, the communication distance up to 21 km. 3. In temperature -40 â?? (using cold battery) - +50 â?? 750 ± 30mm Hg pressure and temperature of +40 â??, relative humidity up to 98% of the reliable work environment. 4. All parts are fixed on the rack into one, along with mobile phones are loaded into the enclosure, solid structure to carry and easy to use. 5. Volume : 222*195*107mm3 ã?? 6. Weight : about2.5Kg -

Type/ Specification Rated Voltage (V) Rated Current (A) Max Analysis Capability(KA) (conΦ=0.35) Electrical Life(times) Mechanical Life (times) Overall Size L�W�H Weight (kg) 1140V 660V KBZ-500/ 1140(660) 1140 500 9 12.5 3000 15000 950�583�982 500 KBZ-630/ 1140 660 600 12.5 15 3000 15000 KBZ-200/ 1140(660) 1140 200 4.5 7.5 3000 15000 791�531�836 320 KBZ-400/ 1140 660 400 7.5 9 3000 15000 KBZ9-200/ 1140(660) 1140 200 4.5 7.5 3000 15000 605�493�826 160 KBZ9-400/1140 660 400 7.5 9 3000 15000 -

Rated voltage 1140V Rated current 630A 500A Ultimate breaking capacity 12.5KA Rated working system Long-term Operation Electric operation, sub-gate Dimensions 960mmx630mmx980mm Weight 490kg -

No. Tech SGB420/30(40) SGB520/40 SGB620/40(55) 1 Delivery volume(t/h) 80(100) 120 150 2 Factory length(m) 100 100 80(100) 3 Head height(mm) 512(620) 620 620 4 Chain speed(m/s) 0.79(0.86) 0.86 0.86 5 Electric motors Model number JDSB30(DSB40) DSB40 DSB40(55) Power(kW) 30(40) 40 40 (55) Number of revolutions(r/min) 1470 1470 1470 Voltage(V) 380/660 380/660 380/660 6 Scraper chain Form Side double-stranded Side double-stranded Side double-stranded Specifications(mm) 14Ã?50(18Ã?64) 18Ã?64 18Ã?64 Breaking load(KN) â?¥190 â?¥320 â?¥320 7 Reducer transmission ratio 1:22.24(1:24.56) 1:24.56 1:24.56 8 Middle slot size (L x W x H) 1200Ã?420Ã?150 (1500Ã?420Ã?180) 1500Ã?520Ã?180 1500Ã?620Ã?180 9 Total weight(t) 10.3(13) 14 15 -

Model Trough Width Transport Speed Material Bulk Density Capacity Conveying Length Installation Angle (mm) (m/s) (t/m3) (m3/h) (m) (degree) MS16 160 ---0.16 m/s ---0.20 m/s ---0.25 m/s ---0.32 m/s 0.2~1.8 t/m3 15~29 < 80m 0°~30° MS20 200 23~46 MS25 250 36~72 MS32 320 59~118 MS40 400 83~166 MS50 500 115~230 -

model MC 16 MC 20 MC 25 MC 32 MC 40 machine width(mm) 160 200 250 320 400 Conveying speed (m/s) 0.16 m/s, 0.20 m/s, 0.25 m/s, 0.32 m/s material bulk density(t/m3) 0.2~1.8 t/m3 delivery value(m3/h) 11~22 15~30 23~46 46~74 55~110 conveyor Height (m) 5~30m setting angle (°) 30°, 45°, 60°, 75°, 90° -

model MSR32 MSR40 Machine groove width (mm) B=320 B=400 Machine groove height (mm) h=320 h=360 Chain speed (m/s) 0.16,0.2,0.25,0.32 0.16,0.2,0.25,0.32 Conveying capacity (m³/h) 8-16 15-30 -

Single stranded scraper conveyor Double strand scraper conveyor Model SGD280/7.5 SGD280/11 SGD320/17 SGB280/11 SGB320/11 SGB320/17 The transportation loses:(t/h) 30 30 40 30 40 50 Completed(m) 40 60 80 50 50 60 Scraper chain (mm) 10*40 10*40 14*50 10*40 10*40 14*50 Chain fast (m/s) 0.514 0.63 0.59 0.63 0.63 0.59 Electrical machinery (Kw) 7.5 11 17 11 11 17 Gross weight (t) 2 2.59 6.02 2.56 3.75 5.2 -

1. Bucket volume 0.17+-0.017M3 2. Technique productivity >=30M3/h 3. Unload height >=1210m 4. Unload distance >=270m 5. Max working height 1920m 6. Gauge 600mm 7. Wheel diameter 850mm 8. Transfer overall dimension (L*W*H) 9. Electric motor speed 10. Working speed about 0.85m/s 11. Bucket promoting speed 0.46-0.71m/s 12. Weight 3500kg -

Model Z-20W Z-20 Loading capacity m3h 30-40 34-40 Bucket volume m3 0.2 0.2 Loading width m 2 2 Track gauge mm 600ï¼?When the track gauge is 750ã?�762ã?�900 Please make a note when bookingï¼? Power Electrical motor Electrical motor Walking power kW 10.5 10.5 Bucket power kW 13 13 Unloading height mm 1360 1330 Machine Dimensions mm Length (when the bucket is Put down) 2400 2400 Width (when the pedal is Put down) 1330 1330 Height (when the bucket is Working) 2180 2180 Height (when the bucket is Put down) 1460 1518 -

Type Z-17AW Z-20 Z-20AW Z-30AW ZQ-26 Loading Capacity (m3/h) 20-30 30-40 30-40 50-60 40-50 Capacity(m3) 0.17 0.2 0.2 0.3 0.26 Loading Width(M) 1.7 2.0 2.0 2.2 2.7 Rail Gauge(mm) 600mm (When the rail gauge is 750mm,762mm, please mark in the order) Power Electric motor Electric motor Electric motor Electric motor wind motor Travel Power(kw) 10.5 10.5 10.5 1.5 10.5 Raising Hopper Power(kw) 10.5 10.5 13 15 15 Discharge Height(mm) 1250 1330 1360 1370 1250 Dimension(mm) Length (bucket down) L 2120 2480 2400 2620 2375 Width (pedal down) 1011 1210 1330 1300 1380 Height (bucket working) H2 1920 2180 2180 2260 2240 Height (bucket down) H1 1200 1518 1460 1545 1455 Weight(kg) 3760 3750 3700 4600 2700 -

ModelZQ-26 Bucket volume0.26M3 Technique productivity52-60M3/h Loading width2500-2700mm Unload height1250mm Unload distance480mm Max. Air consumption11.5-19M3/min Working pressure5-6bar Gauge600mm Wheel diameter1000mm Length2375 Width1370 Height1375 Motor9+15kw Working speedabout 0.79m/s Promoting speed0.46-0.71m/s Weight2700kg -

Parameter of 3 Ton LIFAN Petrol Engine Cable Winch Model Pull Force(KN) Speed(m/min) Engine Weight(kg) JJM3Q 30 4 LIFAN 110 18 8 NO lifting 4 -

Model NO. Engine Gear Pulling Speed(m/min) Rated Pulling Force(Ton) Weight(Kg) ZJM1-Q HONDA Petrol engine 4 HP (Slow) 10.0 0.8 36 (Fast) 15.0 0.6 Reverse 12.0 No Lifting! Electric motor (Slow) 10.0 0.8 46 (Fast) 15.0 0.6 Reverse 12.0 No Lifting! -

1, the carrying capacity of the beam span of 700mm, the beam central concentrated load; 2.weight contains 0.7kg/m weld weight 3.Model specifications differ for each increase of one standard 200mm Characteristic length allowable bending beam load capacity (KN) Weight Model Specification (mm) (KN.m) Min Max (kg/m) DFB.C-1400ï½?4400 1400ï½?4400 52.50 300 400 20.78 DFC.C-1400ï½?4400 1400ï½?4400 35 200 250 17.15 -

Length 800mm,1000mm,1200mm Model DJB-800/420 DJB-1000/300 DJB-1200/300 Material 27simn Width 100mm Height 90mm Thickness 8mm Length 1000mm Processing quenching and tempering (heat treatment) Load capacity larger than 300kN -

Weight:10.2kg/m; Material:27SiMnleg height:45 Outer width:100 Iinner width:83 Waist depth;8 Teeth space:52 Accoss angle 1259#Ï?parameter: Weight;8.26kg/m Material:27SiMn -

KTH17B Max input DC voltage DC52V Max input circuit Current DC 65mA Feed voltage DC48V Bell ringing voltage DC24-48V Net Weight (kg) 1.65kg Size (mm) 285mmÃ?175mmÃ?135mm Communication Distance â?¤5km,model: MHYV1*2*7/0.37 Belling Grade â?¥80dB Material ABS Protection Level IP54 Installation Wall Mounting/ desk top Link coupler KTA16B safe coupler, connect to 10 phones Dial model DTMF Function Explosion proof /waterproof/ anti-dust /anti-corrosion -

Model KTH18 Max input DC voltage DC60V Max input circuit Current 34mA Max input bell stream voltage 60V(25 ±3)HZ Max input bell stream circuit current 38mA Weight (kg) 3.3 Communication Distance �10km,model: MHYV1*2*7/0.37 Anti noise level �75dB Bell ringing level �90dB(A) Material ABS Protection Level IP54 Installation Wall Mounting/Table Linker KTA17 safe coupler Dial model Tone and Pulse Function Explosion proof /waterproof/ anti corrosion/anti dust -

Model KTH15 Max input DC voltage DC66V Max input circuit Current 60mA Max input bell stream voltage 105v Max input bell stream circuit current 120mA Weight (kg) 3.8kg Communication Distance â?¤10km,model: MHYV1*2*7/0.37 Bell ringing level â?¥95dB Material ABS Protection Level IP65 Installation Wall Mounting/Table Linker coupler KTA12 coupler T/P Way Tone and Pulse Function Explosion proof /waterproof/ anti noise -

Rated voltage : DC 3.7V Maximum working current : â?¤ 650 mA Standby current:â?¤80mA Ringing loudness: â?¥70dB Battery : 3`7v/1200mAh Standby time : 72h Duration : 6 hours Receiving sensitivity (dBm/m) : â?¤-75 Communication distance : â?¥100meter Working channel : 13 Dimension : 120mm(L)52mm(W)22mm(H) Weight : 139g -

tem Specification Duration 60min Temperature of air inhaled 60°C(1%CO) Dimensions 73*94*143mm Weight 1kg In storage 5 years In carrying 3 years

ZYX120 Miners Isolated Compressed Oxygen Self Rescuer is mainly composed of the respiratory system and the CO2 filter system of high pressure system,consisting of high pressure system including oxygen bottles,oxygen bottle switch,pressure regulator,automatic and manual supply valve and pressure gauge. Model ZYX120 Protect time â?¥120min Capacity of oxygen bottle 1.0L Oxygen storage capacity 240L Inspiratory oxygen concentration 25% Inhaled carbon dioxide concentration 2% Quantitative supply of oxygen 1.2L/min Manual supply of oxygen supply 60L/min Cylinder filling pressure 20Mpa Period of validity 3-5 years Outline dimensions 285*205*100mm weight 4.3kg

Miners use them to self-rescue when it is oxygen-poor or toxic gas threats their life in coal mine. It can be also applied by the first aiders or workers from other enterprises or public institutions who works under the condition of oxygen deficit or toxic gas. Model ZYX30 Protect time â?¥30min Capacity of oxygen bottle 0.3L Oxygen storage capacity 56L Inspiratory oxygen concentration 25% Inhaled carbon dioxide concentration 2% Quantitative supply of oxygen 1.2L/min Manual supply of oxygen supply 60L/min Cylinder filling pressure 20Mpa Period of validity 3-5 years Outline dimensions 210*167*80mm

SDCK800 Plastering thickness2-28mm Plastering width90cm Plastering height 4.5m Power supply1.5KW Capacity400 m2 to 550m2/8h Power220V/380V Surface Very Smooth Level degree 2mm Perpendicularity degree 2mm Juncture device,Smoothing knifeYes

ZM800-A Electric Automatic Cement Plastering Machine is a new machine instead of handmade in construction plastering area. Model ZM800-A Plastering Height 0-5meters Plastering Thickness 2-25mm Plastering Width 80cm Capacity 450 square meters/8 hours Dimensions 1350Ã?800Ã?500mm Voltage/frequency According to your demands Weight 240kg Surface smooth Vibrator 2 vibrators Juncture device Yes Smoothing knife Yes Perpendicularity degree 2mm Level degree 2mm

Plastering height 0-3.6m Plastering thickness 2-30mm Plastering width 80cm Power supply 2.2KW Capacity 500-750m2/8hours Electricity Phase Single / Three Power 220V/380V50HZ/60HZ Dimensions 800*650*500mm Surface Very Smooth Level degree 2mm Perpendicularity degree 2mm Juncture device,Smoothing knife Yes

ZB800-5A Portable Auto Wall Rendering Machine is the extended version of all our plastering machines. It gathered all the advantages: mini size, flexible operation, simple structure and light weight. Especially suitable for small rooms. lastering height 0-3.6m Plastering thickness 2-30mm Plastering width 80cm Power supply 2.2KW Capacity 800-850m2/8hours Electricity Phase Single / Three Power 220V/380V50HZ/60HZ Dimensions 720*830*680mm Surface Very Smooth Level degree 2mm Perpendicularity degree 2mm Juncture device,Smoothing knife: Yes

Item Auto Plastering Machine Model No: HL-6 Rendering Thickness 5mm-30mm Rendering Speed 70-80m/ hour Rendering Height 3.5m / 4m Dimension(L*W*H) 1000*650*550mm Weight 140kg Electricity Phase Three/Single Phase Voltage 380v / 220v Power 0.75kw

Model (Extra Strength) TY680 Plaster thickness 2-30mm Plaster height Up to 4m Efficiency 400m2/8h Overall size 1000*680*520mm Voltage 220v Weight 140kg Power 2.2kw

Model 110 Product Name High Quality Block Wall Automatic Wall Rendering Machine Price Weight â?¥110KG Dimension 1100x650x3500mm Power 380V/220V,50Kz-60Hz,2.75KW Work efficiency 500-600 Sqm Per Day Plastering Thickness 0.2cm--3.5cm Plastering Width 1100mm Plastering Height 5m Length of Plastering Trowel 1200 MM Portal Frame Unfoldable Position Industry microcomputer automatic vertical system Motor Germany Wanshin Plastering Plate High Speed Steel Electricity Phase Single/Three Phase Beam Available Package Wooden Case Suitable for Long Way Transporation

Model GW40B A3 Round bar 6-32mm II reinforced bar 6-28mm Working mode Hand manual Disc diameter 300mm Bending Speed 20-30pcs/min Motor Power 3KW Input voltage 220VAC 380VAC 415VAC or customized Motro speed 1880r/min Driving mode Worm Gear Size 850*750*800mm Weight 305KGS

Model GW40C A3 Round bar 6-40mm II reinforced bar 6-32mm Working mode Hand manual Disc diameter 350mm Bending Speed 20-30pcs/min Motor Power 3KW Input voltage 220VAC 380VAC 415VAC or customized Motro speed 1880r/min Driving mode Worm gear Size 750*750*730mm Weight 350KGS

Model GW50B 1. Bending round steel diameter 6-50mm 2.Grade thread screw steel diameter 6-42mm 3. Working plate diameter spec 320mm 4. Main shaft speed 8-15r/min 5. Motor spec 4KW/380V 6. Motor speed 1440t/min 7. Dimension 1060, 850, 730mm 8. Net weight/Gross weight 360kgs/380kgs 9. packing size 1100, 900, 900mm

Capacity of loading(L) 560L Power source Diesel engine Engine power 8.82KW Productivity 10-14m ³/h Mixing and raising power 12HP Rotation rate of the mixing drum 14r/min max particle diameter of aggregate 60mm Traction speed 10-15km/h Entire machine weight 2,400kg Hopper lifting model Hydraulic tipping hopper External dimension 2766,2140,3170mm Engine specifications Model S195 Type Single-cylinder, Four-Stroke, horizontal Cylinder bore 95mm Piston stroke 115mm 1 hr. rate output 9.7kw(13.2HP)/2200rpm 12 hr. rate output 8.8kw(12HP)/2200rpm Piston displacement 0.815liter Compression ration 20:01 B.M.E.P 650kpa Specific fuel consumption 251g/kwh Type of cooling Water evaporative Type of starting Electric Opening pressure of fuel injection 12.75+0.98(130+10)Mpa(kg.f/cm2) Overall dimensions(L,M,H) 900,450,760mm Net weight 145kg Type of fuel injection UI-00 Type of nozzle coupling U4-3 Type of injection pump 0 single body rack pump plunger

Item Number Parameter Power Gross Drum Capacity(L) Weight (KGS) Drum Upper Drum Lower Diesel Engine Electric Motor UT35Y No 370W 100/125 55 1.2mm 1.8mm UT35C No 370W 100/125 55 1.2mm 1.8mm UT35H No 370W 100/125 55 1.2mm 1.8mm UT35Z No 370W 100/125 55 1.2mm 1.8mm UT35J No 370W 100/125 55 1.2mm 1.8mm UT35S No 370W 100/125 58 1.2mm 1.8mm UT35L No 370W 100/125 60 1.2mm 1.8mm UT35B NO 370W 100/125 55 1.2mm 1.8mm UT35D 2.5HP Gasoline Engine NO 100/125 59 1.2mm 1.8mm

Model JS1000 Discharge volume 1000L Charging volume 1600L Theoretical capacity 50m3 Aggregate sizes 60/80mm Working circle 60s Mixing blade Speed 25.5r/min Quantity 28 Mixing motor Model Y225S-4 Power 37 kw Lifting motor Model YEZ160L-4 Power 11 kw Pump motor Model KQW65-100 Power 3 kw Weight 9880kg Dimensions (L x W x H) 4640*2250*2250 mm

Model JS750 Discharge volume 750L Charging volume 1200L Theoretical capacity 35m3 Aggregate sizes 60/80m Working circle 60s Mixing blade Speed 30.5r/min Quantity 28 Mixing motor Model Y200L-4 Power 30 kw Lifting motor Model YEZ132M-4 Power 7.5 kw Pump motor Model 65DWB35-5 Power 1.1 kw Weight 6150kg Dimensions (L * W *H) 4550*2250*2450 mm

Technical Parameters Model JN250 JN330 JN500 JN750 JN1000 JN1500 JN2000 JN2500 JN3000 Charging Volume (L) 375 500 750 1125 1500 2250 3000 3750 4500 Discharging Volume (L) 250 330 500 750 1000 1500 2000 2500 3000 Discharging Capacity(kg) 600 800 1200 1800 2400 3600 4800 6000 7200 Diameter of Mixing Drum (mm) 1300 1540 1900 2192 2496 2796 3100 3400 3400 Mixing Power (kw) 11 15 18.5 30 37 55 75 90 110 Discharging Power (kw) 2.2 2.2 2.2 2.2 3 3 4 4 4 Mixing Blades(nr) 1/2 1/2 1/2 1/3 2/4 2/4 3/6 3/6 3/9 Side Scraper 1 1 1 1 1 1 1 1 1 Discharging Scraper - - - 1 1 1 2 2 2 Weightï¼?kgï¼? 1200 1700 2000 3500 6000 7000 8500 10500 11000 Dimension(L*W*H)mm 1570 *1480 *1750 1862 *1850 *1855 2220 *2071 *1880 2550 *2295 *2195 2893 *2606 *2217 3223 *2906 *2425 3625 *3235 *2630 3893 *3555 *2695 3893 *3555 *2975 Lifting Power(kw) 3 4 4 7.5 11 15 18.5 - -

Model ZM-70 Engine Honda G x 390 Power 13 hp Weight 295 kg Spatula number 8 pieces Spatula size 350*150mm Fuel tank capacity 6.5 L Overall dimensions 1710*940*1150mm

JY-36S Concrete Screed is suitable for flat cement and concrete surface during construction building site and road construction and so on. type JY-36S Working Width 1--4m Engine Power 2.5HP Frequency 5500-6500r/min Weight 20KG

Product name YZ25-4 Road Construction Laser Screed Machine Walking model Wheeled type Engine model Kohler CH730-2 gasoline engine Driving method Hydraulic driven Generator power 17.5kw Working width 2500mm Voltage system power 12v Working efficiency 400 m2-600 m2 / hour Fuel consumption rate 2.5L --- 3.2L / H Length *Width * Height (mm) 3200*2900*1700 (mm)

Product name YZ25-4E concrete laser screed machine Walking model Wheeled type Engine model Subaru Robin EH72 Type of gasoline air-cooled 4-stroke, double cylinder Power 25HP Lubricant quantity 1.55 Fuel tank capacity 20L Flattening the flattening of the leveling system Flatten width 2500MM Length x Width x Height (mm) 2890 * 2915 * 1675 mm Paving thickness 60-300 mm Turbo power low speed high torque cycloid hydraulic motor Vibration system control method vibration motor Excitation force 500 N Vibration frequency 50HZ Laser system laser system control mode microcomputer laser scanning Laser system control effect plane, slope, double slope (three-dimensional) Wheel inflatable wide tires Speed 0-45 m / min Mode of operation None Forward and backward remote control Cleaning system power ,external motor Theoretical flow 20 L / min Rated pressure 7 Mpa Weight 650KG

Model: RTM-41 Voltage: DC9.6V Time Of Making A Knot: 0.9 Seconds Ties Per Coil: Approx. 160 Ties(2 Turns) Turns Per Tie: 2 Turns/ 3 Turns Ties Per Charge: 6-7 Coils Length Of Wire For Tying: 600mm/2 Turns ( 780mm/3 Turns ) Dimension(L)X(W)X(H): 285X100X296mm -

Model No. wL-400(Li-ion) Max Tying Diameter 40mm Voltage & Capacity DC14.4V(4.4AH) Charge Time Approx.50mins Tying speed per knot 0.75 seconds Ties per Charge Over 3600 ties Ties per Coil Approx.160ties(3turns) Turns per Tie 2turns/3turns Length of Wire for Tying 600mm/2 turns 780mm/3 turns Wire Type Black annealed wire or Galvanized wire Net Weight) 1.9kgs Dimension(L)X(W)X(H) 295mmX120mmX275mm -

Model 3NB800 3NB1000 3NB1300 3NB500C 3NB1000C 3NB1300C 3NB1600 Power KW(HP) 588(800) 735(1000) 956(1300) 368(500) 735(1000) 956(1300) 1176(1600) Strokes per minutes (pm) 160 150 140 95 110 120 120 Stroke (mm) 216 235 245 254 305 305 305 Gear ratio 2.51 2.658 2.868 3.82 3.833 3.81 3.81 Max. working pressure 33 35 35 30 35 35 35 Max. dia of liner(mm) 160 170 171.5 160 170 180 190 Dia. Of suction pipe (mm) 257 254 257 254 305 305 305 Dia. Of discharge pipe (mm) 100 100 100 100 100 100 100 -

1.Reasonable structure, convenient repair: pump head part is used for before and after the door structure, repair without dismantling piping, just move the motor backwards, can be disassembled and repair the pump. 2.High concentration, no clogging: conveying pulp concentration up to 6%; 3. Cavitation erosion resistance, long service life: the actual service life than ordinary paper pulp pump can be increased by 2-3 times; 4. High efficiency, energy saving: efficiency than ordinary pulp pump average of 3-10 percentage points, saving energy and reducing consumption, up to 15-30% . 5. The impeller and the guard board clearance can be adjusted in a timely manner, maintain higher working efficiency. The pump above the pump body is larger, the structure of open, disassembly and convenient maintenance. 6. Application of water rinse to prevent clogging the pump is stopped. 7. The type of pump in addition to 12PN mud export level, others are vertical upward. 8. PN type pump shaft seal water must be added a certain amount of water, the general work flow of 1-3%, the pressure should be greater than the working pressure of 1 kg / cm 2. 9. 1PN, 2PN, 3PN, 2PNL, 3PNL steering motor direction is clockwise, 4PN, 6PN, 8PN, 10PN, 12PN steering motor direction is counter clockwise. 10. In this type of pump in general use. 11. The PN Horizontal Centrifugal Submersible Slurry Water Mud Pump is not allowed to reverse parking. -

Model N2 semi-automatic Voltage 380V Power 4KW Delivery capacity 3-60L/min Delivery pressure 30bar Delivery distance 0-100m Delivery height 50m Maximum aggregate diameter 3mm Hopper capacity 50L Maximum length of delivery hose 100m Weight 165kg CTNâ??s Dimension 1310*640*1180mm Accessories 15m delivery hose, 1 high pressure gun, 1 low pressure gun, 16m air hose, 20m manual operation wire, key for control box, instruction book, sponge balls, screw and nuts, etc. -

Model N5 completely automatic Voltage 380V Power 4KW Delivery capacity 6-85L/min Delivery pressure 30bar Delivery distance 60m Delivery height 30m Max. aggregate diameter 3mm Hopper capacity 120L Feeding modeCompletely automatic Weight of control case 70kg Weight of delivery parts 95kg Weight of hopper 100kg Overall weight 265kg

Iterm Wall Cement Spray Plaster Mortar Putty Spray Plastering Machines Power 7.5kw Voltage 380V Input pressure 6Mpa Transmission of horizontal distance 60mm Bucket capacity 50L Through the particles -

Model GLP-311 Capacity 3m3/h Working pressure 3Mpa Horizontal convey distance 20m Vertical convey distance 10-20m Main power 380V/5.5kw Max. Diameter of material 4mm Hopper capacity 50L Air compressor 0.3m3/h Overall weight 310kgs -

Working capacity 3--6m3/hr Working pressure 3MPa Horizontal conveying distance 50m Vertical conveying distance 30m Main motor power 7.5kw,380v Screw speed 200---600RPM Max aggregate size 4mm Duct diameter 25/32mm Hopper Capacity 50L Feeding height 800mm Outer size(L*W*H) 1835(1425)*600*1150mm Machine weight 380kg

1. Available model: RC-16, RC-20, RC-22, RC-25, RC-16B, NRC-20 2. Available certificate: CE, RoHS 3. Packing: one set/metal box/carton Voltage 220V/110V Wattage 850W/1170W Gross weight 19.5kg Machine weight 15kg Cutting speed 3.5-4.5 s Max rebar 22MM Min rebar 4MM Package One Pc /Metal Box/Cardboard Ctn Carton Size 460x160x270MM Machine Size 420x120x230MM Certificate CE ROHS

Voltage 220V/110V Wattage 850W/800W Gross weight 17kg Machine weight 12.5kg Cutting speed 4.0-5.0s Max rebar 20MM Min rebar 4MM Package One Pc /Metal Box/Cardboard Ctn Carton Size 430*400*150 Machine Size 360*250*100 Certificate CE ROHS

Model Voltage Wattage Machine Cutting Max Min Machine size(mm) weight speed rebar rebar RC-16 220V/110V 690W/900W 8kg 2.5-3.0s 16mm 4mm 460*270*115 RC-20 220V/110V 950W/1250W 13kg 3.0-3.5s 20mm 4mm 410*115*220 RC-22 220V/110V 1000W/1250W 15kg 3.5-4.5s 22mm 4mm 420*120*230 RC-25 220V/110V 1600W/1700W 24.5kg 3.5-4.5s 25mm 4mm 480*150*255 RC-32 220V/110V 2200W 35KG 5s 32mm 6mm 550*180*270 NRC-20 220V/110V 950W/1300W 12.5kg 3.0-3.5s 20mm 4mm 500*130*140

Model GQ40A Blade 26mm Plain carbon steel �Φ40mm Deformed steel bar �Φ32mm Square steel bar �32mm*32mm steel angle bar �50mm*50mm steel flat bar �70mm*15mm Motor power 3/2.2KW motor speed 2890r/min Voltage 380V/220V Weight 450KG Size 1250*500*730mm G.W.(KGS) 430 N.W.(KGS) 398 -

MO-2050L Industrial Construction Mobile Light Tower is design to meet the lighting requirement of the railway, electric utility, public security, emergency maintenance, disaster relief and rescue, other large construction sites and etc Lamp panel rated voltage 220V working voltage 220V lamp power 250W light capacity 26500LM service lifetime ï¼?100000H Continuous working time main supply long time generator power supply 6 hrs Mast min height 1.2M max height 2.8M Generator rated output voltage 220V rated power 550W fuel tank capacity 4.2L Dimensions lamp and mast 500150350mm generator stand 580470550mm Weight lamp panel 6kg mast/generator /33.5kg -

The metal halide lamp technology is one of the most efficient ways of turning electrical energy into light. It requires less power, produces more light and provides the ideal lighting for working, sport and event areas.The expected lifetime of a metal halide lamp in a normal operation is very long, and the failure ratio is the lowest of all types of lamps. Model QLT M10 Engine Model D1105 E3BG Engine Type 3-cylinder, 4-cycle, liquid -cooled diesel Engine Rated net output 8.4 kW Engine speed 1500 rpm Fuel tank capacity 118 L Continuous working period 71.5 h Engine EPA rating Tier 4 Output Light type Metal halide lamp Light quantity 4 Light power 1000 w/ Light Receptacles 220V industrial waterproof receptacle Lamp pole Max. height 9.2 m Rotation angle 360degrees Operating mode Manual Dimensions and weight (Transporting) Dimensions (L x W x H) 4480mm *1190mm *1680mm Net weight 717 kg Dimensions and weight (Operating) Dimensions (L x W x H) 3210mm * 2850mm * 3810/9440 mm Net Weight 815 kg -

MO-5659 Towable Vehicle Mounted Portable Light Towers is designed to meet the lighting requirement of the railway, electric utility, public security, emergency maintenance, disaster relief and rescue, other large construction sites and etc. Rated voltage 220V Working voltage 220V Lamp panel Lamp power 4x1000Wï¼?standardï¼? Light capacity 85000lm Lamp lifetime 10000h Mast Min height 3M Max height 9M Generator Output voltage 220V Power capacity 7.5KW Retracted dimension 4392*1626*1600mm Gross weight 580 Kg

Features: 1.Adopt metal halide lamp lighting,high brightness,long service life. 2.Height adjustable,prevent fall institutions,strong ability of anti-wind,safe and stable. 3.Waterproof switch box ensures the safety in the rainy day. 4.Manual lifting mechanism,lifting flexible,any height,lock automatically. Generator Set (AC220V/2.2KVA/50HZ Single Phase) 3000rpm Retracted Size 550*350*800 L*W*H(mm) Net Weight 98 KG Gasoline Fuel Tank 15 Liter Working Time with full fuel 13 Hour Noise Level -

ED300B Engine:6.5HP,gasoline Transmission:3 forward+1reverse Brake parkiing:mechanical Stand mode:manual or electric Measurement:1600*660*965mm Max loading capacity:300kg Net weight:180kg Gross weight:210kg Fuel tank capaacity:3.6l Oli capacity:0.6l climbing ability of up to 30 degree inclines -

Engine:9.0HP, gasoline Net weight:282KG Transmission:3 forward+1 reverse Brake parking: mechanical Box length:1000mm Box width:700mm Box depth:460mm Measurement: 1630*720*965mm -

Model WL-210 WL-400 WL-500 Max Tying Diameter 21mm 40mm 50mm Time of Making a Knot 0.8 s 0.8 s 0.8s Battery Type 9.6V Ni-MH 3000mAh 9.6V Ni-MH 3000mAh 9.6V Ni-MH 3000mAh Charge time 1 hour quick charger 1 hour quick charger 1 hour quick charger GW of Machine 2.15kgs 2.2kgs 2.25kgs Max. Number of Tying Knots 1200ties (one Ni-MH battery) 1200ties (one Ni-MH battery) 1200ties (one Ni-MH battery) Wire Type galvanized steel wire, Annealed steel wire galvanized steel wire, Annealed steel wire galvanized steel wire, Annealed steel wire Wire 0.8mm 0.8mm 0.8mm Turns per Tie 2 turns/3turns 2 turns/3turns 3turns/4turns Ties per Coil Approx. 260ties(2turns) Approx.160ties(2turns) Approx. 100 ties(3 turns) Ties per Charge 4-5 Coils 6-7 Coils 7-8 Coils -

1.Size: QU70,QU80,QU100,QU120 2. Material : U71Mn 3.Standard: YB/T5055-93 STANDARD 4.Length: 12M Parameter of U71Mn Standard Crane Rail QU70 Mode Size mm AXBXCXD Weight(kg/m) Length(m) QU70 120x120x70x28 52.80 9/9.5/1010.5/11/11.512/12..5m QU80 130x130x80x32 63.69 9/9.5/1010.5/11/11.512/12..5m QU100 150x150x100x38 88.96 9/9.5/1010.5/11/11.512/12..5m QU120 170x170x120x44 118.10 9/9.5/1010.5/11/11.512/12..5m
