This floorplate-design two-post lift from Dalian Sworld Machinery Co. Ltd. in China is built for workshops with low ground clearance, using a base plate to distribute load and increase ground support stability. The unit lifts 3,500 kg to a maximum height of 1,800 mm, with a minimum platform height of just 125 mm and a full rise cycle time of 40 to 50 seconds. Overall dimensions are 2,830 mm tall by 3,340 mm wide, with 2,850 mm between the columns, and the complete assembly weighs 750 kg. It runs on a 2.2 kW motor compatible with 110V, 230V or 400V power supplies.
The lift uses a dual-cylinder hydraulic system with plate chain and steel wire rope balancing to keep both carriages moving in sync, which reduces the risk of vehicle tilt during operation. A throttling valve on the hydraulic power unit lets the operator control descent speed at any point during lowering. Safety features include a mechanical lock meeting international standards and a self-locking protection device that provides a secondary fail-safe. The manufacturer reports that each unit passes 115% dynamic load testing and 150% static load testing before shipment.
Rubber support pads are supplied in both single-screw and staged height-adjustment configurations, and multiple arm designs are available to suit different vehicle chassis. Auto repair shops, tyre centres, and fleet maintenance facilities across Africa, the Middle East, and Southeast Asia commonly source this type of floorplate lift for passenger cars and light commercial vehicles. Packing dimensions are 2,850 mm by 450 mm by 670 mm, which fits a standard pallet for sea freight. Prospective buyers should confirm the exact arm configuration, voltage variant, and any additional accessories directly with Dalian Sworld Machinery before placing a bulk order.
| Lifting Capacity | 3,500 kg |
| Maximum Lifting Height | 1,800 mm |
| Minimum Platform Height | 125 mm |
| Lift Rise Time | 40-50 seconds |
| Overall Height | 2,830 mm |
| Overall Width | 3,340 mm |
| Width Between Columns | 2,850 mm |
| Motor Power | 2.2 kW |
| Power Supply Options | 110V / 230V / 400V |
| Net Weight | 750 kg |
| Packing Dimensions | 2,850 x 450 x 670 mm |
| Typical Overload Test Standard | 115% dynamic / 150% static (typical for commercial two-post lifts) |
| Typical Hydraulic Fluid Type | ISO VG 32 or VG 46 hydraulic oil (standard for workshop lifts) |
Dalian Sworld Machinery Co. Ltd. is based at No. 54 Jinma Road, Dalian, Liaoning Province, China 114000. The company is listed on the platform with a 'harbor' trust tier, which indicates a basic level of business verification. The listing does not disclose the firm's year of establishment, factory size, number of employees, or annual output, so those details should be requested directly before committing to a large order.
The supplier's profile shows a 0% response rate and an average response time of zero hours, which suggests the account may be newly registered or not yet actively monitored. Buyers are advised to use the platform's direct inquiry tool and allow additional time for a reply, or to request alternative contact details such as a direct email or phone number. The product page lists multiple arm and pad configurations, but the listing does not state whether samples are available or what the minimum order quantity is, both of which are important to clarify during initial negotiations.
| Business Type | Supplier |
| Year Established | Recently Joined |
| Employees | Contact Supplier |
| Annual Revenue | Contact Supplier |
| Main Products | View Products Tab |
| Major Markets | Global |
| Response Time | <4h |
| Response Rate | New Supplier |
Before placing an order with Dalian Sworld Machinery Co. Ltd., verify the exact arm configuration you need, the voltage variant matching your workshop supply, and whether anchor bolts and installation hardware are included in the price. Request the supplier's installation manual and wiring diagram in advance so your local electrician can prepare the site. Also confirm the minimum order quantity, as the listing does not state one, and ask whether a single-unit trial order is possible before committing to a container load.
For logistics, clarify whether the quoted price is FOB Dalian, CIF your destination port, or another Incoterm, and ask for the exact container loading plan based on the stated packing dimensions of 2,850 by 450 by 670 mm. Sea freight from Dalian to ports in West Africa or the Persian Gulf typically takes three to five weeks, so factor this into your project timeline. Insist on a pre-shipment inspection or third-party quality check, especially for the first order, to confirm the units match the advertised specifications and have passed the 115% dynamic and 150% static load tests.
On arrival, inspect the hydraulic cylinders, chain assemblies, and safety locks for shipping damage before signing the delivery receipt. Commission the lift only after verifying that the concrete floor meets the minimum thickness and strength requirements for the anchor bolt pattern specified in the manual. Establish a routine maintenance schedule for the hydraulic fluid level, cable tension, and mechanical lock engagement to ensure safe operation throughout the lift's service life.
